Power Switch/LED Assembly

Description
Power switch/LED assembly
1. Prepare the computer for disassembly
2. Remove the access panel
3. Remove the front bezel
4. Remove the front fan
5. Disconnect the cable from the system board connector labeled PB/LED.
6. With the computer on its side, press on the tabs on the bottom of the assembly (1) to disengage
the assembly from the chassis, and then rotate the bottom of the assembly upward (2) to
remove it from the chassis.
Figure 6-30
7. Pull the assembly away from the chassis while threading the cable through the hole in front of
the chassis.
82 Chapter 6 Removal and Replacement Procedures Microtower (MT) Chassis
(Computer Access Panel on page
(Front Bezel on page
(Front Fan Assembly on page
Removing the power switch/LED
(Preparation for Disassembly on page
55).
56).
79).
Spare part number
646828-001
54).
