MultiModem rCell Intelligent Wireless Router
Configure the Ethernet Interface Using
the Web Management Software
You are now ready to configure the Ethernet interface. This is
accomplished by using the router's factory-installed Web Management
software. The software is accessed through a Web Browser.
1.
From the pc, open a Web Browser.
Type the default Gateway Address:
Note:
Ensure that the Status LED is blinking, indicating that the
router is ready.
2. Login
After entering the Address, the Login screen displays.
●
Type the default User name: admin (all lower-case).
●
Type the default password: admin (all lower-case).
User Name and Password Note:
Password are case-sensitive (both must be typed in lower-case).
A password can be up to 60 characters. If Windows displays the
AutoComplete screen, you may want to click No to tell the
Windows OS not to remember the password; this helps maintain
PC security.
Password Caution:
It is recommended that you change the
default password to better protect the security of your router. Use
a safe password! Your first name spelled backwards is not a
sufficiently safe password; a password such as xfT35$4 is better.
●
Click the Login button. The Web Management Home screen
displays.
3. Use the Setup Wizard for Quick Configuration
A quick way to configure the modem is to use the Wizard Setup in
the Web Management software.
●
To begin configuration, click the Wizard Setup button located
under the menu bar.
●
After clicking the Wizard Setup button, the Wizard Setup
screen displays.
12
Multi-Tech Systems, Inc. Quick Start Guide
http://192.168.2.1
The User name and
