MultiModem rCell Intelligent Wireless Router
Note:
The pc settings must be in the same subnet range as
the router.
The factory default settings for the router are:
IP Address: 192.168.2.1
Subnet Mask: 255.255.255.0
Default Gateway: 192.168.2.2
●
Select Use the following DNS server addresses.
●
Enter the IP Address for the Preferred DNS Server.
Example: 205.171.3.65
●
Click OK.
●
Close the Local Area Properties screen by clicking OK.
●
Close the Control Panel.
●
Repeat these steps for each PC on your network.
AT Command for Verifying Signal Strength
To communicate directly with the cellular modem to verify signal
strength, network registeration, and roaming status, telnet to the modem.
Note:
Ensure that the Status LED is blinking, indicating that the router is
ready.
1.
To Telnet to the modem. You can access the modem thru the Run
icon or from the Command Prompt:
Click Start I Run icon. In the Open window, enter cmd and then
press ENTER.
Click Start I All Programs I Accessories I Command Prompt
●
In the command window, type telnet 192.168.2.1 5000
●
At the Login prompt, type the default user name: admin (all
lower-case). Press ENTER
●
At the Password prompt, type the default pass word: admin
(all lower-case). Press ENTER
2.
In the command window, type AT+CSQ
10
Multi-Tech Systems, Inc. Quick Start Guide
