MatchPort b/g Pro Integration Guide

Table 3-3. Demo Board JP1 Jumper Configuration

JP1 pin/Signal
2/LED12
4/LED11
6/LED10
8/LED9
10/LED8
12/LED7
14/LED6

Table 3-4. Demo Board JP7 Jumper Configuration for CON1

JP7 Function
pin/Signal
2/TXA Jumper 1-2, Send TXD to RS232/485 transceiver.
4/RTSA Jumper 3-4, Send RTS to RS232/485 transceiver. In 485 mode RTS
controls transmit enable.
6/SEL4XXA Jumper 5-6, CP3 high selects 485 mode, low 232 mode. Pin at
transceiver is pulled down to default to 232 mode.
8/RXA Jumper 7-8, Receive RXD from RS232/485 transceiver.
10/CTSA Jumper 9-10, Receive CTS from RS232 transceiver.
12/HDPX4XXA Jumper 11-12. In 485 mode, CP4 selects full duplex when low and
half-duplex when high. Pin at transceiver is pulled down to default to
full duplex.
14/DTRA Jumper 13-14, CP1 drives DTR to RS232 transceiver.
16/DCDA Jumper 15-16, CP2 receives DCD from RS232 transceiver.

Table 3-5. Demo Board JP8 Jumper Configuration for CON2

JP7
pin/Signal
2/TXB
4/RTSB
6/SEL4XXB
8/RXB
10/CTSB
12/HDPX4XXB
14/DTRB
16/DCDB

Table 3-6. Demo Board JP8 Jumper Configuration for CON2

JP7
pin/Signal
2/TXB
4/RTSB
6/SEL4XXB
8/RXB
10/CTSB
12/HDPX4XXB
Function
Jumper 1-2, CP1 Controls LED12
Jumper 3-4, CP2 Controls LED11
Jumper 5-6, CP3 Controls LED10
Jumper 7-8, CP4 Controls LED9
Jumper 9-10, CP5 Controls LED8
Jumper 11-12, CP6 Controls LED7
Jumper 13-14, CP7 Controls LED6
Function
Jumper 1-2, Send TXD to RS232 transceiver.
Jumper 3-4, Send RTS to RS232 transceiver.
Do not add jumper since only RS232 is supported. Pin at
transceiver is pulled down to default to 232 mode.
Jumper 7-8, Receive RXD from RS232 transceiver.
Jumper 9-10, Receive CTS from RS232 transceiver.
Do not add jumper since only RS232 is supported. Pin at
transceiver is pulled down to default to 232 mode.
Jumper 13-14, CP5 drives DTR to RS232 transceiver.
Jumper 15-16, CP6 receives DCD from RS232
transceiver.
Function
Jumper 1-2, Send TXD to RS232 transceiver.
Jumper 3-4, Send RTS to RS232 transceiver.
Do not add jumper since only RS232 is supported. Pin at
transceiver is pulled down to default to 232 mode.
Jumper 7-8, Receive RXD from RS232 transceiver.
Jumper 9-10, Receive CTS from RS232 transceiver.
Do not add jumper since only RS232 is supported. Pin at
transceiver is pulled down to default to 232 mode.
3: Demonstration Kit
