JP7
pin/Signal
b/g Pro
13/CP5
15/CP6
Note:
CP allocation in the tables above is the most straightforward for this
specific board. However any CP can be assigned to any function. To reflect
actual CP use in the eventual product (in case different), jumpers can be
replaced with short wires to allow interchanging of connections.
Note:
Jumper can be replaced with short wire to allow use of a current clamp or <50
milliohm resistor to allow use of voltmeter for current measurements.
If using CPs for any combination of the demo board configurations above, please use the
appropriate CP function selection as shown in Table 3-3 to Table 3-7.
If assigning a CP for any function other than the serial port, remove the jumper for the
associated CP pin from JP7 to avoid conflict with the serial port function.
MatchPort b/g Pro Integration Guide
JP7
pin/Signal
14/DTRB
16/DCDB

Table 3-7. Demo Board JP5 Jumper Configuration

Pin/Signal
Pin/Signal
1/3V3
2/3V3_UUT

Table 3-8. Demo Board Configurable Pin Jumper Configurations

Configurable Pin
JP1 Function
CP1
LED12
CP2
LED11
CP3
LED10
CP4
LED9
CP5
LED8
CP6
LED7
CP7
LED6
Function
Jumper 13-14, CP5 drives DTR to RS232 transceiver.
Jumper 15-16, CP6 receives DCD from RS232
transceiver.
Function
Jumper 1-2, MatchPort module power supply.
JP7,JP8 Function
JP7, CON1 DTR
JP7, CON1 DCD
JP7, CON1 RS485/232 Select
JP7, CON1 RS485 Duplex Select
JP8, CON2 DTR
JP8, CON2 DCD
JP8, leave open
