Dimensions; Figure 2-12. Side Views - Lantronix MatchPort b/g Pro Integration Manual

Category
Flow Control
Network Interfaces
Protocols Supported
Management
Internal Web Server
Custom storage
Security
Average Power
Consumption (at
3.3V)
Weight
Cover Material
Temperature
Warranty
Included Software

Dimensions

The MatchPort b/g Pro dimensions are shown in the following diagrams:
MatchPort b/g Pro Integration Guide
MatchPort b/g Pro
XON/XOFF (software), CTS/RTS (hardware), none
Ethernet 10/100 base TX with Auto Negotiation, and HP Auto MDIX
IEEE802.11bg, with IEEE802.11i/PSK/EAP security.
ARP, UDP, TCP, Telnet, ICMP, SNMP, DHCP, BOOTP,, HTTP, HTTPS,
SMTP, TFTP, FTP, SSL/TLS, SSH, LPD, PPP, Syslog, DNS, RSS, XML
Internal web server, SNMP
Serial login, Telnet login (SSH optional), DeviceInstaller utility,
Serves web pages. Either from built in web manager or custom pages in
onboard FLASH filesystem.
FLASH filesystem with 2.5 MB capacity
Password protection, locking features
0.35 W with Radio and CPU Power Management enabled
0.9 W with Radio and CPU Power Management disabled
1 oz (28 g)
ABS
Operating range: -40°C to +70°C (-40°F to +158°F)
Storage range: -40°C to +85°C (-40°F to 185°F)
2-year limited warranty
Windows™ 98/NT/2000/XP-based Device Installer configuration software and
Windows™-based Com Port Redirector and Secure Com Port Redirector,
DeviceInstaller, and Web-Manager.

Figure 2-12. Side Views

2: Description and Specifications
19
