Configuration Switch Bank

JP1 pin/Signal
1/CP1
3/CP2
5/CP3
7/CP4
9/CP5
11/CP6
13/CP7

Table 3-4. Demo Board JP7 Jumper Configuration for CON1

JP7
pin/Signal
1/TXD1
3/RTS1
5/CP3
7/RXD1
9/CTS1
11/CP4
13/CP1
15/CP2
Table 3-xx. Demo Board JP8 Jumper Configuration for CON2
JP7
pin/Signal
1/TXD2
3/RTS2
5/CP7
7/RXD2
9/CTS2
11/RESERVED
on MatchPort
AR
13/CP5
15/CP6
Note: CP arrangement in the tables above is for demonstration purpose only.
In customers' applications, any CP can be assigned as a function of DTR or
DCD. All CPs can be used as GPIOs.
MatchPort AR™ Integration Guide

Table 3-3. Demo Board JP1 Jumper Configuration

JP1 pin/Signal
2/LED12
4/LED11
6/LED10
8/LED9
10/LED8
12/LED7
14/LED6
JP7 Function
pin/Signal
2/TXA Jumper 1-2, Send TXD to RS232/485 transceiver.
4/RTSA Jumper 3-4, Send RTS to RS232/485 transceiver. In 485 mode
RTS controls transmit enable.
6/SEL4XXA Jumper 5-6, CP3 high selects 485 mode, low 232 mode. Pin at
transceiver is pulled down to default to 232 mode.
8/RXA Jumper 7-8, Receive RXD from RS232/485 transceiver.
10/CTSA Jumper 9-10, Receive CTS from RS232 transceiver.
12/HDPX4XXA Jumper 11-12. In 485 mode, CP4 selects full duplex when low and
half duplex when high. Pin at transceiver is pulled down to default
to full duplex.
14/DTRA Jumper 13-14, CP1 drives DTR to RS232 transceiver.
16/DCDA Jumper 15-16, CP2 receives DCD from RS232 transceiver.
JP7 Function
pin/Signal
2/TXB Jumper 1-2, Send TXD to RS232 transceiver.
4/RTSB Jumper 3-4, Send RTS to RS232 transceiver.
6/SEL4XXB Do not add jumper since only RS232 is supported. Pin at
transceiver is pulled down to default to 232 mode.
8/RXB Jumper 7-8, Receive RXD from RS232 transceiver.
10/CTSB Jumper 9-10, Receive CTS from RS232 transceiver.
12/HDPX4XXB Do not add jumper since only RS232 is supported. Pin at
transceiver is pulled down to default to 232 mode.
14/DTRB Jumper 13-14, CP5 drives DTR to RS232 transceiver.
16/DCDB Jumper 15-16, CP6 receives DCD from RS232
transceiver.
Function
Jumper 1-2, CP1 Controls LED12
Jumper 3-4, CP2 Controls LED11
Jumper 5-6, CP3 Controls LED10
Jumper 7-8, CP4 Controls LED9
Jumper 9-10, CP5 Controls LED8
Jumper 11-12, CP6 Controls LED7
Jumper 13-14, CP7 Controls LED6
