Specifications

Category
CPU
Memory
Firmware
Configuration Pins
Reset Circuit
Serial Interface
Serial Line Formats
Modem Control
Flow Control
Network Interface
Protocols Supported
Management
Internal Web Server
Security
Average Power
Consumption (at
3.3V)
Weight
Cover Material
Temperature
Warranty
Included Software
MatchPort AR™ Integration Guide

Table 2-5. Specifications

MatchPort AR
Lantronix DSTni-FX 32-bit Microprocessor, 166 MHz internal
bus, 83 MHz external bus
4 Mbits Flash and 8 Mbits SDRAM, and can be expanded.
Please contact your Lantronix sales representative if you need
higher memory densities.
Upgradeable via TFTP and FTP
Up to 7 pins if no DTR or DCD is used on serial ports.
RESETIN# is low active and push-button type. Minimum RESETIN#
pulse width is 2 ms at IIL = -500 µA. Reset is also triggered if 3.3V at
pin P1.37 drops below 2.93V typically.
CMOS (Asynchronous) 3.3V - level signals
Speed software selectable and customizable (300 bps to 230400 bps)
7 or 8 data bits, 1-2 Stop bits, Parity: odd, even, none
DTR, DCD using CPs
XON/XOFF (software), CTS/RTS (hardware), none
Ethernet 10/100 base TX with Auto Negotiation, and HP Auto MDIX
ARP, UDP, TCP, Telnet, ICMP, SNMP, DHCP, BOOTP, Auto IP,
HTTP, HTTPS, SMTP, TFTP, FTP
Internal web server, SNMP
Serial login, Telnet login, DeviceInstaller software, SSH
Serves web pages
WEB storage capacity: approx. 1MB
Password protection, locking features
0.67W
1 Oz (28 g)
ABS
Operating range: -40°C to +70°C (-40°F to +158°F)
Storage range: -40°C to +85°C (-40°F to 185°F)
2-year limited warranty
Windows™ 98/NT/2000/XP-based Device Installer configuration
software and Windows™-based Com Port Redirector and Secure Com
Port Redirector, DeviceInstaller, and Web-Manager.
