Supplied Accessories - Icom iF5061D Instruction Manual

D Self ground type microphone hanger con-
nection
When the optional microphone
(HM-152/T) is used:
Connect the microphone hanger to
the vehicle's ground for microphone
on/off hook functions when the op-
tional microphone (HM-152/T) is
used.
Purchase separately
CONNECTION AND MAINTENANCE

■ Supplied Accessories

Non-self ground type
Microphone
Microphone hanger Microphone
and screw set hanger cable
Mounting bracket DC power cable
Flat washers Bracket bolts
Mounting screws
Spring washers
(M5×12)
Nuts
Self-tapping screws
(M5×16)
3
Self ground type
Microphone
OR
Microphone hanger
and screw set
Function name
stickers* 1
2
Sponges*
* 1
Used for labelling the pro-
grammable function keys
according to their assinged
functions.
* 2
Used for the optional unit
installation.
Ask your dealer for details.
