Icom iF5061D Instruction Manual page 9

SCAN ADD/DEL (TAG) KEY
➥ Push to add the channel to, or delete it from, the current
scan group.
1. Push to indicate the scan group, then push [CH Up] or [CH Down]
to select the desired group.
2. Push to add or delete the channel to/from the selected scan
group.
3. Push and hold for 1 sec. to exit the scan group selection mode.
➥ Push this key while scan is paused (a signal is detected)
on a channel (except for priority channel,) the channel is
cleared from the scan group.
Depending on the setting, the cleared channel is added
to the scan group again after the scan is cancelled.
PRIO A/B KEYS
➥ Push to select Priority A or Priority B channel.
➥ Push and hold [Prio A (Rewrite)] or [Prio B (Rewrite)] for
1 sec. to rewrite the operating channel as the Priority A or
Priority B channel.
MR-CH 1/2/3/4 KEYS
Push to select the memory channel 1 to 4 directly.
PANEL DESCRIPTION
MONI (AUDI) KEY
➥ Push to mute and release the CTCSS (DTCS) or 2-tone
squelch mute. Open any squelch/deactivate any mute
while pushing and holding this key. (LMR operation only)
➥ Activates one of (or two of) the following functions on
each channel independently: (PMR operation only)
• Push and hold to un-mute the channel (audio is emitted; 'Audi-
ble' condition).
• Push to mute the channel (sets to 'Inaudible' only).
• Push to un-mute the channel (sets to 'Audible' only).
• Push after the communication is finished to send a 'reset code'.
(5-tone/BIIS operation only)
NOTE: The un-mute condition ('Audible' condition) may
automatically return to the mute condition ('Inaudible'
condition) after a specified period depending on pro-
gramming.
PUBLIC ADDRESS KEY
Push to activate the Public Address (PA) function for voice
amplification. When the PA function is activated, the audio
output can be controlled from the transceiver separately with
[CH Up]/[CH Down].
• This function is available when the external unit, such as a audio
amplifier, speaker, etc. is additionally connected.
• Push this key, then speak into the microphone while pushing and
holding [PTT].
