1
PANEL DESCRIPTION

■ Programmable function keys

The following functions can be assigned to [UP], [DOWN],
[P0], [P1], [P2], [P3] and [P4] programmable function keys.
Consult your Icom dealer or system operator for details con-
cerning your transceivers programming.
INFORMATION:
Depending on the pre-setting, the [A], [B], [C] and [D]
keys on the optional HM-152T
the same as the functions which are programmed to the
[P0], [P1], [P2] and [P3] keys on the transceiver, respec-
tively. Ask your dealer for details.
CH UP AND DOWN KEYS
➥ Push to select an operating channel.
➥ Push to select a transmit code channel after pushing [TX
Code CH Select].
➥ Push to select a DTMF channel after pushing [DTMF Au-
todial].
➥ Push to select a scan group after pushing and holding
[Scan A Start/Stop]/[Scan B Start/Stop] for 1 sec.
3
operate
dtmf microphone
ZONE KEY
Push this key, then select the desired zone using [CH Up]/
[CH Down].
What is "zone"?— Selected channels are assigned to a
zone according to how they are to be used in a group.
For example, 'Staff A' and 'Staff B' are assigned into a
"Business" zone, and 'John' and 'Cindy' are assigned into a
"Private" zone.
ZONE UP AND DOWN KEYS
Push to select an operating zone.
SCAN KEY
➥ Push to start and cancel scanning operation.
• When Power ON Scan function is activated, push to pause the
scanning operation. And the paused scan restarts after the
specified time period has passed.
➥ Push and hold this key for 1 sec. to indicate the scan list,
then push [CH Up] or [CH Down] to select the desired list.
