WARNING Read the instructions before using the machine PRESSURE WASHER MODEL NO: JETSTAR 1900 PART NO: 7333234 OPERATION & MAINTENANCE INSTRUCTIONS LS1110... - Page 2 INTRODUCTION Thank you for purchasing this CLARKE pressure washer. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
-
Page 3: General Safety Rules
4. NEVER allow children or untrained personnel to use this machine. 5. NEVER operate the machine with any of the covers removed. 6. NEVER attempt any repairs to this machine. Always refer to your Clarke dealer. 7. NEVER supply any liquid other than water to the water inlet. -
Page 4: Safety Symbols
SAFETY SYMBOLS WARNING: Do not direct discharge stream at persons or animals. Keep clear of nozzle. WARNING: Never direct spray toward any electrical device or electrical outlet. General Warning, indicates that failing to follow these instructions could result in injury or damage to the machine. To reduce the risk of injury, read the manual before use. -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! Read these electrical safety instructions thoroughly before connecting the product to the mains supply. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. - Page 6 OVERVIEW DESCRIPTION NO DESCRIPTION Handle Pressure Washer Lance Lance Storage Car Brush ON/OFF Switch Spray Gun Assembly Detergent Tank High Pressure Outlet Hose Water Inlet Nozzle Cleaning Tool (not shown) Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 7: Unpacking And Assembly
UNPACKING AND ASSEMBLY Unpack your pressure washer and check to ensure the following items are present. Contact your Clarke dealer immediately if any parts are missing or damaged. • 1 x Pressure Washer • 1 x Gun Assembly • 1 x Pressure Washer Lance •... -
Page 8: Connecting The High Pressure Hose To The Gun Assembly
CONNECTING THE HIGH PRESSURE HOSE TO THE GUN ASSEMBLY 1. Screw the high pressure hose onto the gun assembly. • Tighten the connector, hand tight only, Do not use a spanner. NOTE: Make sure the connection is secure. CONNECT THE WATER SUPPLY Always follow the regulations of you local water supplier. -
Page 9: Using Your Pressure Washer
USING YOUR PRESSURE WASHER 1. Turn the water supply on, making sure that the tap is fully open. WARNING: FAILURE TO TURN ON THE WATER COULD CAUSE DAMAGE TO THE PRESSURE WASHER. 2. Plug the mains power cable into the electricity supply. 3. -
Page 10: Adjusting The Spray
ADJUSTING THE SPRAY The nozzle is adjustable and allows you to adjust the spray from a narrow jet of water to a wide spray. To adjust the nozzle, proceed as follows: 1. Hold the shaft of the pressure washer lance in one hand. 2. -
Page 11: Applying Chemicals And Cleaning Agents
CLARKE Wash & Wax, both available from your CLARKE dealer. 3. When the tank is filled with detergent, replace the lid. 4. Switch ON the pressure washer, release the trigger lock and spray the detergent onto the vehicle, patio etc. -
Page 12: Shutting Down
SHUTTING DOWN When you have finished using the pressure washer, follow the procedure shown below to switch off and disconnect the unit. 1. Press the section of the On/Off switch marked “O”. 2. Turn off the water supply at the tap. -
Page 13: Maintenance
MAINTENANCE WARNING: THE PRESSURE WASHER SHOULD BE DISCONNECTED FROM THE MAINS POWER SOCKET DURING CLEANING OR MAINTENANCE. CLEANING THE NOZZLE If the nozzle becomes clogged with foreign materials such as dirt or calcium, excessive pressure may develop. If the nozzle becomes partially clogged or restricted, the pump pressure will pulsate, clean the nozzle immediately by following the instructions below: 1. -
Page 14: Troubleshooting
TROUBLESHOOTING If the following does not solve your problem, please contact the CLARKE service department. FAULT CAUSE SOLUTION Pressure drop. Air in system. Bleed system by quickly operating trigger several times. Pressure Shortage of water. Turn water tap on fully. -
Page 15: Specifications
SPECIFICATIONS Model JETSTAR 1900 Rated voltage 230/240V AC 50Hz Input power 2000 W Hose length Protection Level IPX5 WATER CONNECTION Max. feed temperature 40 °C Max. feed pressure 0.3 Mpa PERFORMANCE DATA Maximum pump pressure 135 Bar Water flow rate 5.5 I/min. -
Page 16: Exploded Diagram
EXPLODED DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 17: Parts List
PARTS LIST DESCRIPTION PART NO Upper Cover Panel TMC1900H001 Main Switch TMC1900H002 Upper Cover TMC1900H003 Detergent Bottle TMC1900H004 Detergent Bottle Cover TMC1900H005 Switch Box TMC1900H006 Self tapping Screw TMC1900H007 Selftapping Screw TMC1900H008 Motor Housing Pressure Plate TMC1900H009 Motor Housing TMC1900H010 Cover Of Motor Housing TMC1900H011 Flat Gasket Panel... -
Page 18: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 19 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
