- Page 1 POWER WASHER MODEL NO: JETSTAR 1950B PART NO: 7336017 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS DL0425...
-
Page 2: Environmental Recycling Policy
INTRODUCTION Thank you for purchasing this CLARKE Power Washer. This pressure washer is designed for cleaning machines, vehicles, buildings, boats, facades, terraces, gardening tools, etc. by means of a high-pressure water jet (if necessary, with additional cleaning agents). Only use accessories, replacement parts and cleaning agents recommended by CLARKE international. -
Page 3: General Safety Rules
4. NEVER allow children or untrained personnel to use this machine. 5. NEVER operate the machine with any of the covers removed. 6. NEVER attempt any repairs to this machine. Always refer to your Clarke dealer. 7. NEVER supply any liquid other than water to the water inlet. -
Page 4: Symbols On The Machine
20. WARNING: Water that has flowed through a system separator (known as a backflow preventer) is considered non-drinkable. SYMBOLS ON THE MACHINE Read the manual Warning: High level of noise when in use. before use. Wear ear protection Wear safety glasses when using this when using this machine. -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. Connecting it to any other power source may cause damage. - Page 6 OVERVIEW Main Body of Power Washer Hose Spool Clamps Handle Hose Spool Handle Spray Gun 10 Inlet Connector with Filter Nozzle 11 Wheels Lance 12 High Pressure Hose & Spool Detergent Bottle Holder 13 Detergent Bottle Spray Gun & Lance Holder 14 Bag of Screws &...
- Page 7 ASSEMBLY WHEELS 1. Fit the wheels into the wheel slots at the bottom of the main body. 2. Push the wheels into the slots so they sit flush. HANDLE 1. Slide the handle onto the brackets located on top of the main body of the washer.
- Page 8 2. Place the hose spool between the handle and using the 4 screws provided, secure the clamps in position, as shown. 3. Push the hose spool handle into the open end clamp, until it sits flush with the handle collar. 4.
- Page 9 ACCESSORY HOLDERS DETERGENT BOTTLE & POWER CABLE HOLDER 1. Place the detergent bottle & power cable holder on to the rear of the main body of the washer. 2. Using the 2 screws provided, secure the holder in position, as shown. GUN AND LANCE HOLDER 1.
- Page 10 2. Insert the hose into the hose connection port on the underside of the gun, as shown. 3. To release the hose, press the hose release clip in and pull down on the hose. 4. Insert the high pressure hose into the water outlet on the front of the pressure washer as shown.
-
Page 11: Safety Features
SAFETY FEATURES THERMAL SENSOR A thermal sensor protects the motor against overloading. The machine will restart after a few minutes, once the thermal sensor has cooled down. GUN TRIGGER LOCK The gun trigger has a locking device, as shown. When the device is raised and locked into the grooves on the rear of the handle, the gun can not be operated. -
Page 12: Connecting The Mains Water Supply
10 mm available from your CLARKE dealer will be suitable. 4. Connect the supply hose to the water supply. • The water supply must provide a maximum of 5 litres per minute at a maximum of 40°C. -
Page 13: Operation
OPERATION 1. Turn the water supply on, making sure that the tap is fully open. WARNING: FAILURE TO TURN ON THE WATER FULLY COULD CAUSE DAMAGE TO THE POWER WASHER INTERNAL COMPONENTS. WARNING: DO NOT USE THE POWER WASHER IF THE SUPPLY CABLE OR IMPORTANT PARTS OF THE MACHINE ARE DAMAGED, E.G. - Page 14 7. Once the machine has been turned off, release any residual pressure in the system by turning off the water supply and operating the trigger before disconnecting any hose or accessory. CHANGE THE SPRAY PATTERN (NARROW JET/WIDE SPRAY) 1. Hold the shaft of the lance in one hand.
- Page 15 250ml of detergent. • Only use detergents recommended for use with pressure washers such as the CLARKE detergents listed on page 23, available from your CLARKE dealer. 2. Replace the cap. 3. Remove the lance section from the...
-
Page 16: Shutting Down
SHUTTING DOWN When you have finished using the pressure washer, follow the procedure shown below to switch off and disconnect the unit. 1. Set the power switch to the ‘OFF’ position. 2. Turn off the water supply at the tap. 3. -
Page 17: Maintenance
MAINTENANCE WARNING: REMOVE THE PLUG FROM THE SOCKET-OUTLET BEFORE CLEANING OR MAINTENANCE AND WHEN REPLACING PARTS CLEANING THE NOZZLE If the nozzle becomes partially clogged with foreign material such as dirt or limescale, excessive pressure may develop and the pump pressure will pulsate. Clean the nozzle immediately as follows: 1. -
Page 18: Troubleshooting
Fluctuating The pump is drawing in air Check that hoses and connections are pressure airtight Valves are dirty, worn or Contact your nearest CLARKE service sticking centre The water supply is not Increase water pressure, check for sufficient... - Page 19 Clean the inlet water filter Folded hose Unfold any kinks that maybe in the inlet or outlet hoses The washer Pump fuse and/or trigger Contact your nearest CLARKE service turns on and off out of order centre by itself No water supply...
-
Page 20: Product Specifications
PRODUCT SPECIFICATIONS Model Number JETSTAR 1950B Part Number 7336017 Voltage and Frequency 230V/50Hz Electrical Insulation Class Input Power @ Rated Load 1650W Input Current @ Rated Load 6.4A Plug Fuse Rating Duty Cycle S1 Continuous IP Rating IPX5 Working Pressure (Outlet) - Page 21 DECLARATION OF CONFORMITY - UKCA Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 22: Declaration Of Conformity (Ce)
DECLARATION OF CONFORMITY - CE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 23: Associated Products
ASSOCIATED PRODUCTS Concentrated Traffic Film Remover, 5 Litres. Can be used to clean grime off all vehicles. It can also clean engines and chassis. Part Number: 3050821 Heavy Duty Snow Foam, 5 Litres. Can be used to lift the toughest dirt. Suitable for off-road vehicles, tractors, trucks and motorcycles.
