- Page 1 WARNING: Read the instructions before using the machine. POWER WASHER MODEL NO: JET8500B PART NO: 7336021 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS DL0425...
-
Page 2: Environmental Recycling Policy
INTRODUCTION Thank you for purchasing this CLARKE Power Washer. This pressure washer is designed for cleaning machines, vehicles, buildings, boats, facades, terraces, gardening tools, etc. by means of a high-pressure water jet (if necessary, with additional cleaning agents). Only use accessories, replacement parts and cleaning agents recommended by CLARKE international. -
Page 3: General Safety Rules
4. NEVER allow children or untrained personnel to use this machine. 5. NEVER operate the machine with any of the covers removed. 6. NEVER attempt any repairs to this machine. Always refer to your CLARKE dealer. 7. NEVER supply any liquid other than water to the water inlet. -
Page 4: Symbols On The Machine
20. WARNING: Water that has flowed through a system separator (known as a backflow preventer) is considered non-drinkable. SYMBOLS ON THE MACHINE Read the manual Warning: High level of noise when in use. before use. Wear ear protection Wear safety glasses when using this when using this machine. -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved 13 amp BS 1363 plug, or a suitably fused isolator switch. This product may be fitted with a non-rewireable plug. - Page 6 OVERVIEW Main Body of Power Washer Hose Spool Handle Cable Holder 10 Main Handle Wheels 11 Bag of Screws & Nozzle Cleaning Tool Hose Spool Assembly 12 Gun Seat 13 Gun Bracket Lance 14 Rear Shelf & Bottle Holder Inlet Connector with Filter 15 Detergent Bottle Hose Spool Handle Clamp Parts &...
- Page 7 ASSEMBLY WHEELS 1. Fit the wheels into the wheel slots at the bottom of the main body. 2. Push the wheels into the slots so they sit flush. HANDLE 1. Slide the handle onto the brackets located on top of the main body of the washer.
- Page 8 3. Push the hose spool handle into the open end clamp, until it sits flush with the handle collar. 4. The handle can be turned in on itself. This is so that the handle is out the way for storage and it helps lock the spool in place and the hose from unraveling.
- Page 9 GUN BRACKET AND SEAT 1. Slide the gun bracket on to the bracket holder on the side of the washer, as shown. 2. Slide the gun seat holder on to the bracket holder on the side of the washer, as shown. CABLE HOLDER 1.
- Page 10 ASSEMBLING THE SPRAY GUN & HOSE 1. Insert the lance into the gun as shown and twist to lock in place. 2. Insert the hose into the hose connection port on the underside of the gun, as shown. 3. To release the hose, press the hose release clip in and pull down on the hose.
-
Page 11: Safety Features
5. Hand tighten the locking sleeve fully to gain a water tight seal. SAFETY FEATURES THERMAL SENSOR A thermal sensor protects the motor against overloading. The machine will restart after a few minutes, once the thermal sensor has cooled down. GUN TRIGGER LOCK The gun trigger has a locking device, as shown. -
Page 12: Connecting The Mains Water Supply
10 mm available from your CLARKE dealer will be suitable. 4. Connect the supply hose to the water supply. • The water supply must provide a maximum of 6.5 litres per minute at a maximum of 40°C. -
Page 13: Operation
OPERATION 1. Turn the water supply on, making sure that the tap is fully open. WARNING: FAILURE TO TURN ON THE WATER FULLY COULD CAUSE DAMAGE TO THE POWER WASHER INTERNAL COMPONENTS. WARNING: DO NOT USE THE POWER WASHER IF THE SUPPLY CABLE OR IMPORTANT PARTS OF THE MACHINE ARE DAMAGED, E.G. - Page 14 500ml of detergent. • Only use detergents recommended for use with pressure washers such as the CLARKE detergents listed on page 15, available from your CLARKE dealer. NOTE: The amount of detergent used can be adjusted by turning the adjustment cap on top.
- Page 15 4. Use the pressure washer as normal. CLARKE POWER WASHER DETERGENTS • Concentrated Traffic Film Remover, 5 Litres. Can be used to clean grime off all vehicles. It can also clean engines and chassis. Part Number: 3050821 •...
-
Page 16: Shutting Down
SHUTTING DOWN When you have finished using the pressure washer, follow the procedure shown below to switch off and disconnect the unit. 1. Set the power switch to the ‘OFF’ position. 2. Turn off the water supply at the tap. 3. -
Page 17: Maintenance
MAINTENANCE WARNING: REMOVE THE PLUG FROM THE SOCKET-OUTLET BEFORE CLEANING OR MAINTENANCE AND WHEN REPLACING PARTS CLEANING THE NOZZLE If the nozzle becomes partially clogged with foreign material such as dirt or limescale, excessive pressure may develop and the pump pressure will pulsate. Clean the nozzle immediately as follows: 1. -
Page 18: Troubleshooting
Fluctuating The pump is drawing in air Check that hoses and connections are pressure airtight Valves are dirty, worn or Contact your nearest CLARKE service sticking centre The water supply is not Increase water pressure, check for sufficient... - Page 19 Clean the inlet water filter Folded hose Unfold any kinks that maybe in the inlet or outlet hoses The washer Pump fuse and/or trigger Contact your nearest CLARKE service turns on and off out of order centre by itself No water supply...
-
Page 20: Component Parts
COMPONENT PARTS Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 21 COMPONENT PARTS Description Description ON/OFF Switch Strip Left Winding Bracket ON/OFF Switch Connecting Pin Front Cover Faceplate Winding Handle Shaft Front Cover Baseplate Winding Handle Gun Seat Winding Handle Grip Short Outlet Hose Cable Bracket Front Cover Induction Motor/Pump Assembly Main Outlet Hose Insert Hole Baffle Handle Grip...
-
Page 22: Product Specifications
PRODUCT SPECIFICATIONS Model Number JET 8500B Part Number 7336021 Voltage and Frequency 230V/50Hz Electrical Insulation Class Input Power @ Rated Load 2100W Input Current @ Rated Load 7.4A Plug Fuse Rating Duty Cycle S1 Continuous IP Rating IPX5 Working Pressure (Outlet) 110bar / 1590psi Maximum Working Pressure (Outlet) 165bar / 2390psi... -
Page 23: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
