- Page 1 POWER WASHER MODEL NO: JET 7000 PART NO: 7333220 OPERATION & MAINTENANCE INSTRUCTIONS LS1211...
-
Page 2: Parts And Servicing
INTRODUCTION Thank you for purchasing this CLARKE Power Washer. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: General Safety Rules
4. NEVER allow children or untrained personnel to use this machine. 5. NEVER operate the machine with any of the covers removed. 6. NEVER attempt any repairs to this machine. Always refer to your Clarke dealer. 7. NEVER supply any liquid other than water to the water inlet. -
Page 4: Safety Symbols
SAFETY SYMBOLS WARNING: Do not direct discharge stream at persons or animals. Keep clear of nozzle. WARNING: Never direct spray toward any electrical device or electrical outlet. General Warning, indicates that failing to follow these instruction could result in injury or damage to the machine To reduce the risk of injury, Read the manual before use. -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! Read these electrical safety instructions thoroughly before connecting the product to the mains supply. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. - Page 6 OVERVIEW DESCRIPTION NO DESCRIPTION Reel Handle Lance Handle Nozzle Motor Housing Water Inlet Detergent Bottle (Rear of the unit) High Pressure Outlet Hose/Gun Assembly ON/OFF Switch...
-
Page 7: Unpacking And Assembly
UNPACKING AND ASSEMBLY Unpack your power washer and check to ensure the following items are present. Contact your Clarke dealer immediately if any parts are missing or damaged. • Hose/Gun assembly (attached to the reel) • Lance with spray nozzle, •... -
Page 8: Connecting The High Pressure Hose
CONNECTING THE HIGH PRESSURE HOSE 1. Screw the connector on the end of the high pressure hose onto the water outlet pipe. 2. Tighten the connector by hand only. Do not use a spanner. NOTE: Make sure the connection is secure. -
Page 9: Using Your Power Washer
USING YOUR POWER WASHER 1. Turn the water supply on, making sure that the tap is fully open. WARNING: FAILURE TO TURN ON THE WATER COULD CAUSE DAMAGE TO THE PRESSURE WASHER. 2. Plug the mains power cable into the electricity supply. Release the trigger lock. -
Page 10: Adjusting The Spray
ADJUSTING THE SPRAY The nozzle is adjustable to allow you to adjust the spray from a narrow jet of water to a wide spray. To adjust the nozzle, proceed as follows: 1. Hold the shaft of the lance in one hand. -
Page 11: Shutting Down
SHUTTING DOWN When you have finished using the pressure washer, follow the procedure shown below to switch off and disconnect the unit. 1. Press the section of the On/Off switch marked “O”. 2. Turn off the water supply at the tap. -
Page 12: Maintenance
MAINTENANCE WARNING: THE MACHINE SHALL BE DISCONNECTED FROM ITS POWER SOURCE BY REMOVING THE PLUG FROM THE SOCKET-OUTLET DURING CLEANING OR MAINTENANCE AND WHEN REPLACING PARTS. CLEANING THE NOZZLE If the nozzle becomes clogged with foreign materials such as dirt or calcium, excessive pressure may develop. -
Page 13: Before Storing The Pressure Washer
STORAGE PROCEDURE Make sure that the power washer has been thoroughly cleaned before storing it in a clean dry place. ACCESSORIES There are a range of accessories available from your Clarke dealer including the following... -
Page 14: Troubleshooting
TROUBLESHOOTING If the following does not solve your problem, please contact the CLARKE service department. See page 2 FAULT CAUSE SOLUTION Pressure drop. Air in system. Bleed system by quickly operating trigger several times. If necessary operate the machine briefly without the high pressure hose connected. -
Page 15: Specifications
SPECIFICATIONS Model JET 7000 Rated voltage 230V AC 50Hz Input power 1800 W Maximum operating pressure 100 Bar Maximum rated flow 6.5 lpm Hose length ° Maximum inlet water temperature Minimum feed volume 400 l/h = 6.6L per minute Inlet pressure maximum 6 Bar Protection Level IPX5... -
Page 16: Exploded Diagram And Parts List
EXPLODED DIAGRAM AND PARTS LIST... - Page 17 WARNING: TO ENSURE KIT 5 PISTON BODY 10007200 MACHINE SAFETY, USE ONLY ASSEMBLY ORIGINAL SPARE PARTS FROM KIT 6 PISTON ASSEMBLY 10010300 CLARKE INTERNATIONAL. KIT 7 PILOT SLEEVE 10010200 ASSEMBLY KIT 8 PUMP BODY 10007300 ASSEMBLY KIT 9 ONE-WAY VALVE...
-
