DFI NF4 SLI INFINITY User Manual page 60

2
Hardware Installation
Installing the Graphics Cards
1. To install the first graphics card, remove the screw of the bracket
that is opposite the PCIE1 slot then remove the bracket.
2. Align the graphics card above the PCIE1 slot then press it down
firmly until it is completely seated in the slot.
3. Secure the graphics card with the screw you removed in step 1.
4. To install the second graphics card, remove the screw of the
bracket that is opposite the PCIE3 slot then remove the bracket.
5. Align the graphics card above the PCIE3 slot then press it down
firmly until it is completely seated in the slot.
6. Secure the graphics card with the screw you removed in step 4.
The illustration below shows the locations of PCIE1 and PCIE3
slots.
60
Important:
Use two identical NVIDIA SLI-ready PCI Express x16 graphics
cards.
PCIE1
PCIE3
