Hardware Installation
Front Audio
The front audio connector (J4) allows you to connect to the line-out
and mic-in jacks that are at the front panel of your system. Using
this connector will disable the rear audio's line-out and mic-in func-
tions.
Remove the jumper caps from pins 5-6 and pins 9-10 of J4 prior to
connecting the front audio cable connector. Make sure pin 1 of the
cable connector is aligned with pin 1 of J4. If you are not using this
connector, make sure to replace the jumper caps back to their
original pin locations.
Driver Installation
Install the "Realtek Audio Drivers". An audio software application
program will at the same time be installed into your system. Refer to
chapter 4 for more information.
42
2-channel
Light Blue Line-in
Lime Line-out
Pink Mic-in
Pins 5-6 and 9-10 short
(default)
Pins 5-6 and 9-10 open
6-channel
4-channel
Rear R/L
Rear R/L
Front R/L
Front R/L
Center/Subwoofer
Mic-in
The front audio is disabled.
The rear audio is enabled.
The front audio is enabled.
The rear audio is disabled.
