Installing.SoundPoint

This section provides basic installation
instructions and information for obtaining
the best performance with the Sound-
Point IP 600/601 SIP phone. If you re-
®
quire additional information or assistance
with your new phone, please contact your
system administrator.

Powering Options for the SoundPoint

Both the SoundPoint
from Power over Ethernet in addition to AC power sources.
For Power over Ethernet, both models will accept power over stan-
dards-based IEEE802.3af via the used or unused pairs over the Ether-
net cables plugged ino the LAN port.
For AC power source, both models are shipped with an adapter to
convert the AC voltage to the appropriate DC voltage required.
► There are differences between the DC voltages required by the SoundPoint
IP 600 and IP 601:
SoundPoint IP 600
®
Requires a 12VDC rated power adapter as
supplied in the original packaging. Power
over Ethernet under the IEEE802.3af
standard also supplies sufficient wattage
to power the SoundPoint
without use of the adapter above.
SoundPoint IP 601
®
Requires a 24VDC rated power adapter as
supplied in the original packaging. The
24VDC adapter supplies sufficient wattage
to power the SoundPoint
and up to three SoundPoint
Modules (optional accessories). Power
over Ethernet under the IEEE802.3af
When powering from an AC voltage source,
it is important to use only that power adapter
that shipped with the appropriate phone.
Powering a SoundPoint ® IP 600 phone from
a SoundPoint ® IP 601 phone adapter, or
IP 600 and SoundPoint
®
IP 600 phone
®
IP 601 phone
®
IP Expansion
®

.IP.600/601.SIP

®
The SoundPoint
Guide includes regulatory compliance
information that your system administra-
tor should review and can also be found at
www.polycom.com.
IP 600/601
®
IP 601 can be powered
®
standard also supplies sufficient wattage
to power the SoundPoint
and up to three SoundPoint
Modules.
vice-versa, cannot guarantee correct operation
over all input conditions. If in doubt about
the appropriate power adapter that ships with
your unit, contact your system administrator
for futher details and/or options.

IP 600/601 SIP User
®
IP 601 phone
®
IP Expansion
®
®
