Installing.SoundPoint
This section provides basic installation
instructions and information for obtaining
the best performance with the Sound-
®
Point
IP 301 SIP phone. If you require
additional information or assistance with
your new phone, please contact your sys-
tem administrator.
Connecting Network and Power Source
AC Power Option
Connect the supplied Network Cable
between the LAN jack on the phone and
the LAN port on the wall or hub/switch
device port. Connect the DC plug of the
AC wall adapter into the supplied LAN
cable as shown.
Power over Ethernet (PoE) Option
Using an Inline Power Cable (optional acces-
sory from Polycom), the phone can be alter-
nately powered from a Power over Ethernet
(PoE) compliant switch or hub. Inline Power
Cables exist for both IEEE 802.3af and Cisco
pre-standard PoE options. Plug the keyed end
of the Inline Power Cable into the LAN jack
on the phone and the other end to an available
port on the POE switch or hub.
Cisco™Catalyst™ In-Line
Power Switch
IEEE 802.3af compliant
In-Line Power switch
.IP.301.SIP
®
The SoundPoint
includes regulatory compliance informa-
tion that your system administrator should
review and can also be found at: www.
polycom.com
2
®
IP 301 SIP User Guide
Cisco™ In-Line Power
Cable
(Part No. 2200-11014-002 Rev A)
OR
IEEE 802.3af In-Line
Power Cable
(Part No. 2200-11077-002 Rev A)
