Pro-Form 790e Elliptical Manual page 8

3. Orient the Rear Stabilizer (62) and the Rear
Frame (2) as shown.
Tip: If the Ramp Cover (see step 16) is
attached to the Ramp (3), remove the Ramp
Cover.
Attach the Rear Stabilizer (62) to the Rear
Frame (2) with two M8 x 56mm Screws (94) and
two M8 Split Washers (83).
4. Insert the Rear Frame (2) into the Front Frame
(1); make sure that the Ramp (3) is on the Lift
Roller (12).
Attach the Rear Frame (2) with five M8 x 19mm
Screws (82) and five M8 Split Washers (83).
3
62
94 83
4
3
8
3
2
82
12
83
1
2
83
83
82
82
