Pro-Form 790e Elliptical Manual page 11

9. Attach an Outer Cover (67) to the Inner Cover
(68) on the Right Upper Body Leg (60) with two
M4 x 16mm Screws (104).
Repeat this step on the other side of the
elliptical.
10. Have a second person hold the Console (7) near
the Upright (4).
Connect the wires on the Console (7) to the
Ground Wire (120), to the Pulse Wires (63, 69),
and to the Upper Wire Harness (110).
Insert the excess wires into the Upright (4).
Tip: Avoid pinching the wires. Attach the
Console (7) to the Upright (4) with four M4 x
16mm Screws (104).
9
104
10
7
69
110
11
104
68
67
60
Avoid pinching
the wires
63 120
4
104
