11. Orient the Rear Upright Cover (80) as shown.
Attach the Rear Upright Cover (80) to the Upright
(4) with two M4 x 16mm Screws (104).
12. Orient the Front Upright Cover (91) as shown.
Attach the Front Upright Cover (91) around the
Upright (4) by pressing the tabs on the Front
Upright Cover into the Rear Upright Cover (80).
11
80
12
80
12
104
4
91
4
