BASE SERVER STANDARD CAPABILITIES and FEATURES

Table 1 lists the capabilities and features of the base server. Details about how to configure the server for
a particular feature or capability (for example, number of processors, disk drives, or amount of memory)
are provided in CONFIGURING the SERVER on page
Table 1 Capabilities and Features
Capability/Feature
Chassis
CPU
Chipset
Memory
USB Flash drive
Expansion slots
Cisco UCS C460 M2 High-Performance Rack-Mount Server
Description
Four rack unit (4RU) chassis
Either 2 or 4 Intel® Xeon® E7-8800/4800 family processors
Two-CPU configurations require 2 power supplies
Four-CPU configurations require 4 power supplies
Intel® 7500 chipset and Intel 7510 scalable memory buffer
Eight slots for memory riser boards. Each memory riser can hold up to 8
DIMMs, for a maximum DIMM population of 64 DIMMs.
Maximum memory capacity is 2 TB. This is accomplished with 64 DIMMs,
consisting of 32 DIMM kits (2 32 GB matched DIMMs per kit) in a 4-CPU
configuration.
Optional 2 GB internal eUSB flash drives (up to 2) can be used as bootable
drives
There are 10 PCIe expansion slots:
Slots 1 and 2: Gen 2x8, 3/4 length card, x24 hot-swappable connectors
■
Slots 3 and 4: Gen 2x4, 1/2 length card, x8 connectors
■
Slot 5: Gen 2x16, 3/4 length card, x16 connector
■
Slots 6 and 7: Gen 2x8, 3/4 length card, x8 hot-swappable connectors
■
Slot 8: Gen 1x4, 3/4 length card, x8 connector
■
Slot 9: Gen 1x4, 1/2 length card, x8 connector
■
Slot 10: Gen 2x4, 1/2 length card, x8 connector
■
NOTE: CPU3 must be installed to support PCIe slots 5, 6, 7, 9, and
10. Legacy I/O devices like video cards are only supported on slots
1,2,3, 4 and 8.
