CONFIGURING the SERVER
DIMMs are orderable as kits, with two DIMMs per kit. Choose the desired number of DIMMs and
the memory mirroring option if desired. The available memory DIMMs are listed in
Table 5 Available DDR3 DIMM Kits (2 DIMMs per Kit)
Product ID (PID) PID Description
DIMM Options
UCS-MR-2X041RX-C 2X4GB DDR3-1333-MHz RDIMM/PC3-10600/single rank/x4/1.35v 1.5/1.35
UCS-MR-2X082RX-C 2X8GB DDR3-1333-MHz RDIMM/PC3-10600/dual rank/x2/1.35v
UCS-MR-2X164RX-C 2X16GB DDR3-1333-MHz RDIMM/PC3-10600/quad rank/x4/1.35v 1.5/1.35
UCS-MR-2X324RX-C 2x32GB DDR3-1333-MHz RDIMM/PC3-10600/quad rank/x4/1.35v 1.5/1.35
Memory Mirroring Option
N01-MMIRROR Memory mirroring option
Approved Configurations
(1) Minimum Configuration without memory mirroring
One memory riser with at least one matched DIMM pair. The memory riser must be installed
■
in a slot controlled by either CPU1 or CPU2. All four CPUs can run from a single DIMM pair.
(2) Maximum Configuration without memory mirroring
Eight memory risers with at least one matched DIMM pair per riser (16 DIMMs total) and up to
■
four matched DIMM pairs per riser (64 DIMMs total).
(3) Minimum Configuration with memory mirroring
One memory riser with at least two matched DIMM pairs.
■
(4) Maximum Configuration with memory mirroring
Eight memory risers with at least two matched DIMM pairs per riser (16 DIMMs total) and up
■
to four matched DIMM pairs per riser (64 DIMMs total).
16
NOTE: There are three memory mirroring modes:
1 Intra-socket mirroring
2 Inter-socket cross-memory-controller mirroring
3 Inter-socket complete master-slave mirroring
Mirroring mode can be configured using the UCS Manager BIOS Policy RAS Memory
tab
Cisco UCS C460 M2 High-Performance Rack-Mount Server
Table 5.
Ranks/
Voltage (V)
DIMM
1
1.5/1.35 2
4
4
