TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS

Dimensions and Weight

Table 29 UCS C460 M2 Dimensions and Weight
Parameter
Height
Width
Depth
Front Clearance
Side Clearance
Rear Clearance
Weight (maximum configuration, including slide
rail brackets and cable management arm)
Notes . . .
1. The system weight given here is an estimate for a fully configured system and will vary depending on the
number of peripheral devices and power supplies.

Power Specifications

The general power specifications for the C460 M2 server are listed in
Table 30 UCS C460 M2 Power Specifications
Description
AC input voltage
AC input frequency
Maximum AC input current
Maximum AC inrush current
Maximum output power for each
power supply
Power supply output voltage
Power supply efficiency
54
Specification
100 to 127 VAC nominal (Range: 90 to 264 VAC)
50 to 60 Hz nominal (Range: 47 to 63 Hz)
9 A at 100 VAC
30 A peak sub-cycle duration
850 W
Main power: 12 VDC
Standby Power: 5 VDC
92% Peak, complies with 80Plus Gold Standard
NOTE: AC input connector is an IEC 320 C-14 15A/250VAC power inlet.
1
Value
6.8 in. (174 mm)
16.7 in.(424 mm)
27.7 in. (704 mm)
3 in. (7.62 cm)
1 in. (25.4 mm)
6 in. (152.4 mm)
*
110.23 lbs (50 kg)
Table
Cisco UCS C460 M2 High-Performance Rack-Mount Server
30.
