Chassis Front View

Figure 2 is a detailed front view of the Cisco UCS C460 M2 General-Purpose Rack Server.
Figure 2 Chassis Front View
2
1 HDDs (up to 12)
2 SATA DVD drive
3 Fans (up to 8)
4 Power supply status LED
5 Memory status LED
Figure 3 is a detailed view of operator panel.
4
3
4 5
1
6
7
8
9
10
Cisco UCS C460 M2 High-Performance Rack-Mount Server
6 7 8
CPU status LED
Network activity LED
Operations panel (see Figure 3 on page 5
detailed view)
VGA connector
USB ports (3)
9 10
for a
