CONFIGURING the SERVER
STEP 4 CHOOSE HARD DISK DRIVEs or SOLID STATE DRIVEs
The standard disk drive features are:
2.5-inch small form factor
■
Hot-pluggable
■
Sled-mounted
■
Choose Drives
The available drives are listed in
Table 6 Available Hot-Pluggable Sled-Mounted HDDs and SSDs
Product ID (PID)
HDDs
A03-D146GC2
A03-D300GA2
UCS-HDD300GI2F105
A03-D500GC3
A03-D600GA2
UCS-HDD900GI2F106
A03-D1TBSATA
SSDs
UCS-SD100G0KA2-E
UCS-SD100G0KA2-G
UCS-SD200G0KA2-E
UCS-SD300G0KA2-E
UCS-SD400G0KA2-G
Approved Configurations
(1) LSI MegaRAID SAS 9260-8i RAID controller (battery backup is optional)
Select up to 12 SAS or SATA drives listed in
■
HDD/SSD drives). This configuration supports RAID 0, 1, 5, 6, and 10.
(2) LSI MegaRAID SAS 9240-8i RAID controller (no battery backup)
18
Table 6.
PID Description
146 GB SAS 15K RPM SFF HDD
300 GB 6 Gb SAS 10K RPM SFF HDD
300 GB 6 Gb SAS 15K RPM SFF HDD
500 GB 6 Gb SATA 7.2K RPM SFF
600 GB 6 Gb SAS 10K RPM SFF HDD
900 GB 6Gb SAS 10K RPM SFF HDD
1 TB SATA 7.2K RPM SFF HDD
100 GB SATA 2.5 inch Enterprise Performance SSD
100 GB 2.5 inch Enterprise Value SSD
200 GB 2.5 SATA Enterprise performance SSD
300 GB 2.5 SATA Enterprise performance SSD
400 GB 2.5 Enterprise Value SSD
Table 6 (you can mix SAS/SATA drives, but not
Cisco UCS C460 M2 High-Performance Rack-Mount Server
Drive
Capacity
Type
SAS 146 GB
SAS 300 GB
SAS 300 GB
SATA 500 GB
SAS 600 GB
SAS 900 GB
SATA 1 TB
SATA 100 GB
SATA 100 GB
SATA 200 GB
SATA 300 GB
SATA 400 GB
