Table 8 Available PCIe Option Cards (continued)
Product ID (PID)
UCS Storage Accelerators
UCSC-F-FIO-3000M
UCSC-F-FIO-1205M
UCSC-F-FIO-785M
UCSC-F-FIO-365M
Computing Processor Accessory Kit
UCSC-GPU-N01-C460
Notes . . .
1. The NVIDIA Tesla card itself can be ordered from a certified NVIDIA Tesla reseller partner or distributor listed at
the following link: http://www.nvidia.com/object/tesla_wtb.html#3. Note that the C2050 is a full-height PCIe
x16 dual-slot form factor card and consumes 238 watts (max). It can be installed only in PCIe slot 5.
Approved Configurations
(1) Select up to 10 PCIe Cards
Use Table 9
■
Table 9 PCIe Expansion Slot Numbering
Slot Number
1 and 2
3 and 4
5
6 and 7
8
9
10
Cisco UCS C460 M2 High-Performance Rack-Mount Server
PID Description
Cisco UCS 3.0 TB MLC Fusion ioDrive2 for C-Series Servers
Cisco UCS 1205 GB MLC Fusion ioDrive2 for C-Series Servers
Cisco UCS 785 GB MLC Fusion ioDrive2 for C-Series Servers
Cisco UCS 365GB MLC Fusion ioDrive2 for C-Series Servers
Accessory Kit for NVIDIA Tesla C2050 GPU
panels)
as a guide for adding PCIe cards. See
Slot Characteristics
PCIe Gen 2x8, 3/4 length card, x24 hot-swappable connectors
PCIe Gen 2x4, 1/2 length card, x8 connectors
PCIe Gen 2x16, 3/4 length card, x16 connector
PCIe Gen 2x8, 3/4 length card, x8 hot-swappable connectors
PCIe Gen 1x4, 3/4 length card, x8 connector
PCIe Gen 1x4, 1/2 length card, x8 connector
PCIe Gen 2x4, 1/2 length card, x8 connector
CONFIGURING the SERVER
1 includes power cable,
Figure 6 for the slot locations.
Card
Height
Full
Half
Half
Half
N/A
