BASE SERVER STANDARD CAPABILITIES and FEATURES
Table 1 Capabilities and Features (continued)
Capability/Feature
Storage controller
Internal storage devices
Video
Interfaces
8
Description
Factory-configured RAID support options:
RAID 0, 1, 5, 6, 10, 50, and 60 support for up to 12 SAS or SATA drives
■
with either the optional LSI MegaRAID SAS 9260-8i controller, or
RAID 0 and 1 support for up to 8 SAS or SATA drives with the optional LSI
■
MegaRAID 9240-8I RAID controller.
There is a dedicated SAS riser slot in the chassis for either RAID controller
card.
There is also a location inside the chassis for the optional LSI RAID battery
backup unit that can be used with the 9260-8i controller card.
Up to 12 SFF 2.5" SAS or SATA hard disk drives (HDDs) or solid state drives
(SSDs).
UCS Storage Accelerators are also available. These PCIe flash storage devices
provide independent high-speed storage.
The server CIMC chip includes a Matrox G200 core. The first 8 MB of memory
are allocated to the video core.
1280 x 1024 resolution
■
32-bit color depth
■
8 MB video memory
■
Rear panel
■
• Two 10/100 dedicated management Ethernet ports
• Two 1-Gigabit ports (10/100/1000 Mbps capable). These integrated
Gigabit ports support the Wake on LAN (WoL) and TCP/IP Offload
Engine (TOE) standards
• Two 10-Gigabit Base-T Ethernet ports
• Two 10-Gigabit SFP+ Ethernet ports
• One RS232 serial connector
• One 15-pin VGA connector
• Two USB 2.0 connectors
Front panel
■
• One 15-pin VGA connector
• Three USB 2.0 connectors
Cisco UCS C460 M2 High-Performance Rack-Mount Server
