Summary of Contents for NetComm MyWay YMLO-3G8WV
- Page 1 NETCOMM LIBERTY SERIES NetComm MyWay 3G WiFi Router with Voice User Guide YMLO-3G3WV NetComm MyWay – 3G WiFi Router with Voice User Guide www.netcomm.com.au...
- Page 2 Disconnect the power line from the device before servicing. Copyright Copyright©2010 NetComm Limited. All rights reserved. The information contained herein is proprietary to NetComm Limited. No part of this document may be translated, transcribed, reproduced, in any form, or by any means without prior written consent of NetComm Limited NOTE:This document is subject to change without notice.
-
Page 3: Table Of Contents
5.3 Wireless Settings .........................................28 5.4 Firewall ..........................................34 5.5 Administration ........................................37 6. FAQ ........................................42 7. Legal & Regulatory Information ..............................44 7.1 FCC Warning ........................................44 7.2 IC Important Note ........................................45 YMLO-3G3WV NetComm MyWay – 3G WiFi Router with Voice User Guide www.netcomm.com.au... - Page 4 Introduction...
-
Page 5: Introduction
1 Introduction The NetComm MyWay creates a secure WiFi network, providing Internet access and simultaneous phone service using a 3G network. With a quick and easy setup the MyWay provides a landline experience without the need for fixed line connections. Simply insert an active 3G SIM card into the slot on the rear panel and get instant access to a 3G Internet connection within seconds. - Page 6 Basic Setup...
-
Page 7: Basic Setup
For example, change the phone to channel 1 and move your MyWay to channel 11. See your phone’s user manual for detailed instructions. • If necessary, consider switching to a 900MHz or 5GHz cordless phone. YMLO-3G3WV NetComm MyWay – 3G WiFi Router with Voice User Guide www.netcomm.com.au... -
Page 8: Choose The "Quietest" Channel For Your Wireless Network
Reset/WPS Hold and release this button for less than 10 seconds to enable the WPS push-button-connect function. Power Power connector, connects to a DC 12V 1.5A Power Adapter NetComm MyWay – 3G WiFi Router with Voice User Guide YMLO-3G8WV www.netcomm.com.au... -
Page 9: Network And System Requirements
5. Open your Web browser, type http://my.router or http://192.168.20.1 into the address bar and press enter. 6. Follow the steps to set up your MyWay. 7. After the setup process is completed you will be connected to the Internet. YMLO-3G3WV NetComm MyWay – 3G WiFi Router with Voice User Guide www.netcomm.com.au... -
Page 10: Myway Default Settings
Refer to your wireless security card or label on the bottom of your MyWay. *For security purpose, each MyWay comes with a unique SSID that varies by a 4 digit number at the end eg. SSID: “NetComm Wireless 1234.” MyWay Web Interface Access... - Page 11 Select ‘Disable’ to hide the SSID of your MyWay. If disabled, other people will not be able scan and detect your MyWay’s SSID. Configure your Wireless settings in this page then click “Next”; YMLO-3G3WV NetComm MyWay – 3G WiFi Router with Voice User Guide www.netcomm.com.au...
-
Page 12: Management Console Login Procedure
Please Note – If you forget the username and password you selected during the MyWay set-up process, holding the reset button for over 10 seconds will restart the unit with the original settings (username: admin / password: admin). NetComm MyWay – 3G WiFi Router with Voice User Guide YMLO-3G8WV... - Page 13 Using the NetComm MyWay to Make and Receive Telephone calls...
-
Page 14: Using The Myway To Make And Receive Telephone Calls
If no phone is connected the MyWay, all incoming calls will be transferred to Voicemail (if enabled on the device). 3.5 Accessing voicemail To access your voicemail, please refer to voice user manual provide from your service provider NetComm MyWay – 3G WiFi Router with Voice User Guide YMLO-3G8WV www.netcomm.com.au... -
Page 15: Call Feature Codes
Call Forwarding No Answer is disabled if you hear 2 high pitch beeps. b. Call Forwarding No Answer is enabled if you hear 2 low pitch beeps. YMLO-3G3WV NetComm MyWay – 3G WiFi Router with Voice User Guide www.netcomm.com.au... - Page 16 Verify that the RJ-11 cable is securely connected and not damaged. • Try to remove any telephone splitters from the connection between your phone and the MyWay. • Try rebooting your MyWay. NetComm MyWay – 3G WiFi Router with Voice User Guide YMLO-3G8WV www.netcomm.com.au...
- Page 17 Management Console...
-
Page 18: Management Console
Ethernet WAN connection (from an xDSL modem/ISDN/Satellite etc) and a 3G connection. To configure your WAN settings according to your network environment, please switch to advanced view “Internet Settings” then select ”WAN”. Click “Save and apply settings” to finish. NetComm MyWay – 3G WiFi Router with Voice User Guide YMLO-3G8WV www.netcomm.com.au... -
Page 19: Wireless
The default WPA-PSK key is printed on the wireless security card and on the Product ID on the bottom of the MyWay. Please note that whilst the key can be customized on this page, the key will revert to the default if the MyWay is reset to factory default. YMLO-3G3WV NetComm MyWay – 3G WiFi Router with Voice User Guide www.netcomm.com.au... - Page 20 Advanced Features...
-
Page 21: Advanced Features
To view either WAN, PPPoE or PPTP status individually, click on their relevant buttons below the green menu bar. To view them all, click on the All Status button. YMLO-3G3WV NetComm MyWay – 3G WiFi Router with Voice User Guide www.netcomm.com.au... -
Page 22: Internet Settings
The WAN page allows you to configure the optional WAN Ethernet port. Select the WAN connection type suitable for your environment and configure parameters according to the selected connection type. NetComm MyWay – 3G WiFi Router with Voice User Guide YMLO-3G8WV... - Page 23 Internet. If you are using a computer which used to connect to Internet via a cable modem, you can simply press the ‘Default’ button to fill the MAC address field with the MAC address of your computer. Click ‘Apply’ to save the settings. YMLO-3G3WV NetComm MyWay – 3G WiFi Router with Voice User Guide www.netcomm.com.au...
- Page 24 Internet. If you are using a computer which used to connect to the Internet via a cable modem, you can simply press the ‘Default’ button to fill the MAC address field with the MAC address of your computer. Click ‘Apply’ to save the settings. NetComm MyWay – 3G WiFi Router with Voice User Guide YMLO-3G8WV www.netcomm.com.au...
- Page 25 The default value is 20; please enter the valid value from 1 to 9999 suitable for your network environment Internet Host Enter an Internet address here to check the Internet Connection. The default value is www.netcomm.com.au. Click’ Apply’ to save the settings.
- Page 26 PPPoE relay The default is “Disable”, select “Enable” to enable it. DNS Proxy The default is “Enable”, select “Disable” to disable it. Click ‘Apply’ to save the settings. NetComm MyWay – 3G WiFi Router with Voice User Guide YMLO-3G8WV www.netcomm.com.au...
- Page 27 MyWay. Please note that this list is stored in the device’s volatile memory, and is therefore cleared if the device is reset or if any changed are applied to configuration. YMLO-3G3WV NetComm MyWay – 3G WiFi Router with Voice User Guide www.netcomm.com.au...
-
Page 28: Wireless Settings
Each WDS Access Point needs to be set with the same channel and encryption type. Click ‘Apply’ to save the settings. NetComm MyWay – 3G WiFi Router with Voice User Guide YMLO-3G8WV www.netcomm.com.au... - Page 29 Select ‘Disabled’ to hide the SSID of your MyWay. If disabled, other people will not be able scan and detect this Name (SSID): product’s SSID. Click Apply to save the settings. YMLO-3G3WV NetComm MyWay – 3G WiFi Router with Voice User Guide www.netcomm.com.au...
- Page 30 PSK, WPA-PSK-WPA2-PSK, WPA1-WPA2 or 802.1x. WEP (Wired Equivalent Privacy) helps prevent against unwanted wireless users accessing your MyWay. It offers a lower level of security in comparison to WPA-PSK and WPA2-PSK. NetComm MyWay – 3G WiFi Router with Voice User Guide YMLO-3G8WV www.netcomm.com.au...
- Page 31 Your MyWay uses WPA-PSK by default. Check your Wireless Security Card or device label on the bottom of the MyWay for your default SSID and Security key to begin connecting your wireless devices. YMLO-3G3WV NetComm MyWay – 3G WiFi Router with Voice User Guide www.netcomm.com.au...
- Page 32 WPA-PSK (when the wireless client supports WPA-PSK) in order to secure your network. Most wireless adapters in computers and laptops support at least WEP and WPA. NetComm MyWay – 3G WiFi Router with Voice User Guide YMLO-3G8WV...
- Page 33 This is the WPS PIN code of the wireless router. You may need this information when connecting to other WPS- enabled wireless devices. WPS Mode: Select either PIN mode or PBC (which is the WPA via Push Button). YMLO-3G3WV NetComm MyWay – 3G WiFi Router with Voice User Guide www.netcomm.com.au...
-
Page 34: Firewall
Source Port Range of the filter rule Action: Either accept or drop the packet that matches the rule Comment: Add a comment to identify the rule (optional) Click ‘Apply’ to save the settings. NetComm MyWay – 3G WiFi Router with Voice User Guide YMLO-3G8WV www.netcomm.com.au... - Page 35 Fill in the IP address of a particular host in your LAN Network that will receive all the packets originally going to the WAN port/Public IP address of your MyWay. Click ‘Apply’ to save the above configurations. YMLO-3G3WV NetComm MyWay – 3G WiFi Router with Voice User Guide www.netcomm.com.au...
-
Page 36: System Security
Block access to a website by entering its full URL address and clicking Add. Rules can be deleted at any time via this page. Host Filter: Block access to certain websites by entering a keyword. Rules can be deleted at any time via this page. NetComm MyWay – 3G WiFi Router with Voice User Guide YMLO-3G8WV www.netcomm.com.au... -
Page 37: Administration
Please note that a reduction in the WiFi power output can potentially reduce coverage, data throughput speeds, and stability. If you are having problems with your WiFi coverage, stability, or throughput speed, please disable the Green AP functionality. Click ‘Apply’ to save the settings. YMLO-3G3WV NetComm MyWay – 3G WiFi Router with Voice User Guide www.netcomm.com.au... - Page 38 The upgrade process takes several minutes, so please be patient whilst this process is carried out. All lights on the front of the MyWay will flash during the firmware upgrade. Please make sure the power supply is uninterrupted during the upgrade process. NetComm MyWay – 3G WiFi Router with Voice User Guide YMLO-3G8WV...
- Page 39 This page allows you to import/export the system settings, reset your MyWay to factory defaults, or reboot your MyWay. 5.5.6 Statistics This page allows you to view the LAN, WAN and wireless statistics of your MyWay. YMLO-3G3WV NetComm MyWay – 3G WiFi Router with Voice User Guide www.netcomm.com.au...
- Page 40 5.5.7 System Log All important system events are logged. You can use this page to check the log of your MyWay for troubleshooting and diagnostic purposes. NetComm MyWay – 3G WiFi Router with Voice User Guide YMLO-3G8WV www.netcomm.com.au...
- Page 41 Frequently Asked Questions...
-
Page 42: Faq
If a SIM is installed correctly this may indicate that the SIM has been removed or inserted whilst the unit is powered up. In this case you must reboot the unit. The Reset button on the home page will reboot the router. NetComm MyWay – 3G WiFi Router with Voice User Guide YMLO-3G8WV... - Page 43 Appendix...
-
Page 44: Legal & Regulatory Information
(3) The power supply that is provided with this unit is only intended for use with this product. Do not use this power supply with any other product or do not use any other power supply that is not approved for use with this product by NetComm. Failure to do so may cause damage to this product, fire or result in personal injury. -
Page 45: Ic Important Note
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. YMLO-3G3WV NetComm MyWay – 3G WiFi Router with Voice User Guide www.netcomm.com.au... - Page 46 Note: NetComm Technical Support for this product only covers the basic installation and features outlined in the Quick Start Guide. For further information regarding the advanced features of this product, please refer to the configuring sections in the User Guide or contact a Network Specialist.
