Master/Slave Linking
DMX Linking
Each fixture must be
individually set to DMX
mode and addressed.
Please see the section on
DMX addressing.
4. Operating Instructions
MASTER
SLAVE
SLAVE
(DMX Controller)
Fixture #1
Fixture #2
Fixture #3
11
DMX Out not used
Master/Slave Out
31 slave fixtures max
Master/Slave Out
not used
Additional signal
8/9/2010 11:50 AM
link out
