Fixture Linking

You will need a serial data link to run light shows of one or more fixtures using a DMX controller
or to run synchronized shows on two or more fixtures set to a master/slave operating mode. The
combined number of channels required by all the fixtures on a serial data link determines the
number of fixtures the data link can support.
Fixtures on a serial data link must be daisy chained in one single line. To comply with the
EIA-485 standard, no more than 32 fixtures should be connected on one data link.
Connecting more than 32 fixtures on one serial data link without the use of a DMX
optically-isolated splitter may result in deterioration of the digital DMX signal.

Data Cabling

To link fixtures together you must obtain data cables. You can purchase CHAUVET® certified
DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create
your own cable please use data-grade cables that can carry a high quality signal and are less
prone to electromagnetic interference.

DMX Data Cable

Use a Belden© 9841 or equivalent cable which meets the specifications for EIA RS-485
applications. Standard microphone cables cannot transmit DMX data reliably over long distances.
The cable must have the following characteristics:
5. Appendix
Maximum recommended serial data link distance: 500 m (1640 ft)
Maximum recommended number of fixtures on a serial data link: 32
Type:
Maximum capacitance between conductors:
Maximum capacitance between conductor and shield:
Maximum resistance:
Nominal impedance:
15
shielded, 2-conductor twisted pair
30 pF/ft
55 pF/ft
20 ohms/1000 ft
100 ~ 140 ohms
