ATT (Front End Attenuator)

Under conditions of extremely high signal levels, the
front end attenuator may be engaged, either singly
or in conjunction with the IPO feature, to reduce re-
ceiver sensitivity.
Pressing the front panel's [ATT] key repeatedly
causes the attenuator to cycle through the various
levels of attenuation provided (in 1 S-Unit steps of 6
dB each):
6 dB Þ 12 dB Þ 18 dB Þ 0 dB Þ 6 dB Þ . . .
The "0 dB" position, of course, represents the "At-
tenuator Off" configuration.

Digital Voice Recorder Operation (DVR)

The FT-920 includes a built-in Digital Voice Recorder
which you can use to record and then replay the in-
coming signal (from the VFO-A path) for a period of
up to 16 seconds. In addition, the DVR may be used
for storage and replay of repetitive ("CQ" type) mes-
sages in your voice. See the section on 'Transmis-
sion" (page 50) for details of the latter feature.
Recording and playback of incoming signals is
straightforward.
Q While receiving, press the [R
(50 MHz), to start recording. The recording level
is set automatically, so you may leave the listen-
ing volume at a level which is comfortable for you.
During recording, the hyphen in the Memory
Channel display field will blink.
R To stop recording, press the [R
tarily again. The last 16 seconds of incoming au-
dio will now be stored. In this way, you can quickly
confirm, for example, if a DX station correctly cop-
ied your callsign through a pile-up.
S To play back the stored audio, press [P
[0] (50 MHz). For playback, the front panel's [AF
G ] control sets the volume level. Incoming sig-
AIN
nals, however, will be cut off for the duration of
the audio memory playback.
46
] switch, then [0]
EC
] switch momen-
EC
] then
LAY
