Line Select Menu

The instrument must be in the Waveform, Vector, or WIP operating
mode before you can display the Line Select menu.
Enter the Waveform, Vector, or WIP operating mode. Press the LINE
SEL button to turn on Line Select mode and open the Line Select
menu. The number of the selected line and/or field displays in the
menu bar over the right two Bezel Buttons.
The Line Select menu is shown in Figure 2- - 6 on page 2- - 24 and the
Line Select menu choices are shown in Table 2- - 9. For more
information about Line Select, refer to Line Select Mode on
page 2- - 17.

Table 2- 9: Line Select menu choices

Selection
FIELDS ALL
FIELDS 1 OF 2
WFM90D and WFM91D User Manual
Function
Selects all video fields for display. The two right bezel
buttons select which line number is displayed. The menu
bar over these two buttons displays the selected line
number.
When 1 OF 2 is selected, the menu selection ALT FIELD
appears. This allows you to select the video field in which
the selected line is displayed.
Using the Menus
2- 37
