1
PANEL DESCRIPTION
' ' Function display
q TRANSMIT INDICATOR
Appears during PTT on.
w BUSY INDICATOR
Appears while receiving a signal or when the squelch is open.
e LOW POWER INDICATOR (p. 12)
Appears when low output power is selected.
r SCRAMBLER INDICATOR
Appears while the scrambler function is operating.
t KEY LOCK INDICATOR (p. 11)
Appears during key lock function ON.
y BELL INDICATION
Appears or blinks when the optional 5Tone call is received.
u AUDIBLE INDICATOR
Appears when monitor function is turned ON. (CTCSS and DTCS
mutes are released.)
i LOW BATTERY INDICATOR [
-When
capacity is low and transmitting is impossible.
-When
o S-meter
Show the received signal strength
!0 ALPHANUMERIC INDICATOR
3
q w
e r t y u i
appears, battery
flashes, battery capacity is nearly exhausted.
!0
o
]
