CONVENTIONAL OPERATION

' ' Tx code channel selection

Your radio may be programmed for Tx code channel selection. In

this case, you can choose a Tx code channel to be transmitted

when using the call function (p. 17).

Push the Tx code channel switch (assigned to one of the dealer-

programmable switches) to activate the function, then enter digits

via the keypad to select the desired Tx code channel.

• The selected code channel (containing a pre-programmed 5-tone

code) is transmitted when using the call function.

Depending on programming, you may be able to send 5-tone codes

manually.

Push the Tx code switch to activate the function, then enter the de-

sired transmit code (up to 7 digits) using the keypad.

• Activate the call function to transmit the 5-tone code.

• Blinking indicates keypad entry is acceptable.

D D TIME-OUT TIMER

After continuous transmission for a pre-programmed period, the

time-out timer is activated, causing the transceiver to stop transmit-

ting and automatically select receive.

D D PENALTY TIMER

Once the time-out timer is activated, transmission is further inhibited

for a period determined by the penalty timer.
