Programmable Function Keys - Icom IC-400PRO Instruction Manual

8

PROGRAMMABLE FUNCTION KEYS

MONITOR KEY
Activates one of (or two of) the following functions on each
channel independently:
• Push and hold the key to unmute the channel (audio is emitted;
'Audible' condition).
• Push the key to toggle between the mute and unmute conditions
(toggles between 'Audible' and 'Inaudible').
• Push the key to mute the channel (sets to 'Inaudible' only).
• Push the key to unmute the channel (sets to 'Audible' only).
• Push the key after communication is finished to send a 'reset code'.
NOTE: The unmute condition ('Audible' condition) may
automatically return to the mute condition ('Inaudible' con-
dition) after a specified period depending on the pre-set-
ting.
WIDE/NARROW KEY (Private bank only)
Push this key to toggle the bandwidth between wide or nar-
row.
DTMF AUTODIAL KEY
Push this key to display the text of the DTMF channel number
and set the desired channel number via the [CH Up]/[CH
Down] key. Then, push this key again to transmit a specified
DTMF code.
RE-DIAL KEY
Push to send the last transmitted DTMF code.
35
CALL KEY
➥ Push to transmit the 5tone code on the selected channel.
➥ Push and hold to enter the 5tone code channel/number
selection mode. (pgs. 17, 18)
• Push [CH Up]/[CH Down] to select the desired channel/ num-
ber.
ID-MR SELECT KEY
➥ Push to recall the received ID code.
Push [CH Up]/[CH Down] to select the record.
HOOK SCAN
Push to turn the hanger action scan function (automatic scan
start when on hook) OFF temporarily, and push again to turn
the function ON.
ATS/S-RING KEY
➥ Push to transmit the Smart-ring signal to the other station.
➥ Push for 1 sec. to turn the ATS function ON and OFF.
CH LOCK KEY
This function electronically locks [CH Up], [CH Down], [Scan
Start/Stop], [MR-CH 1] to [MR-CH 4], [ID MR Select] and
[Hook Scan] keys to prevent accidental channel change.
