Da-Lite TENSIONED HORIZON ELECTROL Instruction Book

Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
The
POWER
In
PRESENTATION PRODUCTS
DA-LITE SCREEN COMPANY, INC.
Instruction Book for
3100 North Detroit Street
Post Office Box 137
Warsaw, Indiana 46581-0137
®
TENSIONED HORIZON ELECTROL
Phone: 574-267-8101
800-622-3737
Fax: 574-267-7804
Toll Free Fax: 877-325-4832
www.da-lite.com
e-mail: info@da-lite.com

Advertisement

Table of Contents
loading

Related Manuals for Da-Lite TENSIONED HORIZON ELECTROL

Summary of Contents for Da-Lite TENSIONED HORIZON ELECTROL

  • Page 1 POWER PRESENTATION PRODUCTS DA-LITE SCREEN COMPANY, INC. Instruction Book for 3100 North Detroit Street Post Office Box 137 Warsaw, Indiana 46581-0137 ® TENSIONED HORIZON ELECTROL Phone: 574-267-8101 800-622-3737 Fax: 574-267-7804 Toll Free Fax: 877-325-4832 www.da-lite.com e-mail: info@da-lite.com...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS When using your video equipment, basic safety precautions should always be followed, including the following: 1. Read and understand all instructions before using. 2. Position the cord so that it will not be tripped over, pulled, or contact hot surfaces. 3.

  • Page 3: Installation

    8. Unplug the transformer located on the non-motor end of the screen. 9. Remove the receptacle cover plate. Install electrical hook up as shown in the wiring diagram. NOTE: Screen has been internally wired at Da-Lite. Wiring designated “external” is completed by installer conforming to local and national codes.
  • Page 4 SCREEN ADJUSTMENT SCREEN ADJUSTMENT (MOTOR 1) 1. Make sure the power is disconnected to the screen before starting. 2. Remove the cover plate from the wall switch, and then remove the switch from the box. 3. Unplug the T6 cable marked motor 2 from the T6 adapter. 4.
  • Page 5 120V WIRING DIAGRAM T6 = 6 CONDUCTOR TELEPHONE WIRE T4 = 4 CONDUCTOR TELEPHONE WIRE = SINGLE CONDUCTOR 18 AWG MAX. DRY CONTACT REQUIREMENTS: 1. CONTACT CLOSURE MUST BE MAINTAINED FOR AT LEAST 1 SECOND AND NOT MORE THAN 3 SECONDS. INTERFACE UNIT 2.
  • Page 6 SUGGESTED METHODS OF INSTALLATION 9” SELECT INSTALLATION METHOD ACCORDING TO CEILING TYPE. 8-11/16” NOTE: MUST MARK HOLE LOCATION OF SCREWS IN 3-1/2” PANEL FOR REMOVAL, CASE LENGTH = SCREEN FABRIC WIDTH IF COVERING WITH TILE. + 15-3/4”, ALL SIZES 7-7/8” 1-1/2”...

  • Page 7: Troubleshooting

    TROUBLESHOOTING SYMPTOM CAUSE SOLUTION 1. Screen or mask will not operate. (a) Blown facility fuse. (a) Replace facility fuse. Motor does not hum. (b) Tripped facility circuit breaker. (b) Reset facility circuit breaker. (c) No power to receptacle in junction (c) Check above.
  • Page 8 Printed in U.S.A. 83503 Rev. 12/07...
