I Connector information

MICROPHONE
q u
w
i y
e t
r
Front panel view
AF/MOD
5 1
15 11
Front panel view
*NOTE: Onput signal levels between pins 3/4 and 13/14, will influence each other because these pins are connected in paral-
lel. When a 2nd 600 Ω impedance device is additionally connected, adjust the 2nd device to the specified signal levels
for the output (pins 3/4 and 13/14) signal levels of the connected 600 Ω impedance device (reception).
† Input signal from pins 1/2 or 11/12 are acceptable only when transmitted with the SEND signal from 5 or 15, respec-
tively.
62
Pin Pin name
1 MIC+ Audio input from the mic element.
2 NC No connection.
3 AF1 AF output controlled with [VOL].
4 AF2 Ground for AF1.
5 PTT PTT switch input.
6 GND Connected to the ground.
7 MIC– Coaxial ground for MIC+.
8 AF– Coaxial ground for AF1 and AF2.
Pin Pin name
1 † MOD+ Modulation input from an NBDP.
(J2B operation only)
2 † MOD– Coaxial ground for MOD+.
3* AF+ AF detector output for an NBDP.
(J2B operation only)
4* AF– Coaxial ground for AF+.
5 SEND Transmission control line for an
NBDP (transmits when grounded:
J2B operation only).
6 NC No connection.
7 13.6 Outputs 13.6 V DC.
8 NC No connection.
9, 10 GND Ground terminals.
11 † MOD+ Modulation input from an external
terminal unit for SSB.
12 † MOD– Coaxial ground for MOD+.
13* AF+ AF detector output for an external
terminal unit for SSB.
14* AF– Coaxial ground for AF+.
15 SEND Transmission control line for an
external unit for SSB (transmits
when grounded).
Description
Input impedance : 2.4 kΩ
When grounded, transmits.
Description
Input impedance : 600 Ω
Input level
Output impedance: 600 Ω
Output level
Output level
Input level
Input impedance : 600 Ω
Input level
Output impedance: 600 Ω
Output level
Output level
Input level
Specification
Specification
: Approx. 0.77 V rms.
: 0.25–2.5 V rms
: –0.5 to 0.8 V
: Less than 20 mA
: Approx. 0.77 V rms.
: 0.25–2.5 V rms
: –0.5 to 0.8 V
: Less than 20 mA
