Rs-232 Interface - Gefen ex-tend-it 4x4 DVI Matrix User Manual

Binary Table
ASCII Corresponding
RMT16-IR
Button
1
2
3
4
5
6
7
8
RS232 Settings
Bits per second ....................................................................................... 19200
Data bits .......................................................................................................... 8
Parity ........................................................................................................ None
Stop bits ...........................................................................................................1
Flow Control ............................................................................................. None

RS-232 INTERFACE

Binary
1 0011 0001
2 0011 0010
3 0011 0011
4 0011 0100
5 0011 0101
6 0011 0110
7 0011 0111
8 0011 1000
ASCII Corresponding
RMT16-IR
Button
9
a
b
c
d
e
f
g
8
Binary
9 0011 1001
10 0110 0001
11 0110 0010
12 0110 0011
13 0110 0100
14 0110 0101
15 0110 0110
16 0110 0111
