Summary of Contents for Crestron TSW-UMB-PMK
- Page 1 Crestron TSW-UMB-PMK Pre-Construction Mounting Kit for TSW-UMB Installation Guide...
- Page 2 States and/or other countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or photography.
-
Page 3: Table Of Contents
Crestron TSW-UMB-PMK Pre-Construction Mounting Kit Contents Pre-Construction Mounting Kit for TSW-UMB: TSW-UMB-PMK Introduction ..........................1 Installation ..........................4 Resources ........................... 5 Further Inquiries ......................5 Future Updates ......................5 Return and Warranty Policies ....................6 Merchandise Returns / Repair Service ................ 6 Crestron Limited Warranty .................. -
Page 5: Pre-Construction Mounting Kit For Tsw-Umb: Tsw-Umb-Pmk
TSW-750 , or TSW-1050 touch screen (all sold separately). The TSW-UMB-PMK permits fastening to the left or right-hand stud of a framed wall prior to the installation of drywall. 1. The TSW-550 actually ships with (1) TSW-UMB and (1) TSW-UMB-PMK included. - Page 6 Pre-Construction Mounting Kit Crestron TSW-UMB-PMK TSW-UMB-PMK Overall Dimensions (Front View) 7.50 in (191 mm) 4.50 in (115 mm) TSW-UMB-PMK Overall Dimensions (Side View) 1.50 in (39 mm) 2 • Pre-Construction Mounting Kit: TSW-UMB-PMK Installation Guide – DOC. 7607A...
- Page 7 Crestron TSW-UMB-PMK Pre-Construction Mounting Kit TSW-UMB-PMK Cutout Dimensions 3 3/4 in (96 mm) 2 1/2 in (64 mm) Installation Guide – DOC. 7607A Pre-Construction Mounting Kit: TSW-UMB-PMK • 3...
-
Page 8: Installation
Installation CAUTION: Allow an air gap of at least 12 inches (305 mm) in the wall cavity above and below the TSW-UMB-PMK for heat dissipation. For pre-construction applications, use standard drywall nails or screws to attach the TSW-UMB-PMK to a wall stud. -
Page 9: Resources
[1-888-273-7876] or, for assistance within a particular geographic region, refer to the listing of Crestron worldwide offices at www.crestron.com/offices. To post a question about Crestron products, log onto Crestron’s Online Help at www.crestron.com/onlinehelp. First-time users must establish a user account to fully benefit from all available features. -
Page 10: Return And Warranty Policies
(property or economic damages inclusive) arising from the sale or use of this equipment. Crestron is not liable for any claim made by a third party or made by the purchaser for a third party. - Page 11 Crestron TSW-UMB-PMK Pre-Construction Mounting Kit This page is intentionally left blank. Installation Guide – DOC. 7607A Pre-Construction Mounting Kit: TSW-UMB-PMK • 7...
- Page 12 Crestron Electronics, Inc. Installation Guide – DOC. 7607A 15 Volvo Drive Rockleigh, NJ 07647 (2038168) Tel: 888.CRESTRON 11.13 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
