Crestron TSW-550-BBI
Wall Mount Back Box for TSW-550
International Version
Installation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TSW-550-BBI and is the answer not in the manual?

Questions and answers

Summary of Contents for Crestron TSW-550-BBI

  • Page 1 Crestron TSW-550-BBI Wall Mount Back Box for TSW-550 International Version Installation Guide...
  • Page 2 States and/or other countries. Other trademarks, registered trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or photography.
  • Page 3: Table Of Contents

    Crestron TSW-550-BBI Wall Mount Back Box for TSW-550 Contents Wall Mount Back Box for TSW-550: TSW-550-BBI Description ..........................1 Installation ..........................3 Resources ........................... 6 Further Inquiries ......................6 Future Updates ......................6 Return and Warranty Policies ....................7 Merchandise Returns / Repair Service ................ 7 Crestron Limited Warranty ..................
  • Page 5: Wall Mount Back Box For Tsw-550: Tsw-550-Bbi

    Wall Mount Back Box for TSW-550 Wall Mount Back Box for TSW-550: TSW-550-BBI Description The TSW-550-BBI provides a recess wall-mounted metal back box for ® the Crestron TSW-550 5” Touch Screen. It is designed for installation in concrete and masonry applications. Conduit knockouts are provided on the top and bottom.
  • Page 6 Wall Mount Back Box for TSW-550 Crestron TSW-550-BBI The dimensions of the TSW-550-BBI are shown in the following illustrations. TSW-550-BBI Overall Dimensions (Top, Front and Side Views) 105 mm 77 mm (4.13 in) (3.00 in) 68 mm (2.65 in) NOTE: Knockout holes are intended for Class 2 wiring only and are 20 mm (13/16”) diameter.
  • Page 7: Installation

    Crestron TSW-550-BBI Wall Mount Back Box for TSW-550 Installation The hardware supplied with the TSW-550-BBI is listed in the following table. Supplied Hardware for the TSW-550-BBI DESCRIPTION PART QUANTITY NUMBER Assembly, Back Box, International 4518364 Screw, #06-32 x 1/2”, Flat, Phil...
  • Page 8 Crestron TSW-550-BBI 3. Use the two #06-32 x 1/2” screws (2007241) that come with the TSW-550-BBI to install the front part of the mounting bracket assembly onto the back box. Refer to the following illustration. Install Mounting Bracket into TSW-550-BBI...
  • Page 9 Wall Mount Back Box for TSW-550 4. Make sure the “TOP” text on the inside of the back box is facing upward. Mount the TSW-550-BBI as shown in the following illustration. Depending on the installation, forced ventilation may be required.
  • Page 10: Resources

    Crestron Web site (www.crestron.com/offices) for assistance within a particular geographic region. To post a question about Crestron products, log onto the Online Help section of the Crestron Web site (www.crestron.com/onlinehelp). First-time users must establish a user account to fully benefit from all available features.
  • Page 11: Return And Warranty Policies

    (property or economic damages inclusive) arising from the sale or use of this equipment. Crestron is not liable for any claim made by a third party or made by the purchaser for a third party.
  • Page 12 Crestron Electronics, Inc. Installation Guide – DOC. 7519A 15 Volvo Drive Rockleigh, NJ 07647 (2036297) Tel: 888.CRESTRON 04.13 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
