- Page 1 Crestron TSW-730-MSMK Multi-Surface Mount Kit for TSW-730 Installation Guide...
-
Page 2: Table Of Contents
Other trademarks, registered trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or photography. -
Page 3: Multi-Surface Mount Kit For Tsw-730: Tsw-730-Msmk
TSW-730-MSMK-B-S Black Smooth TSW-730-MSMK-W-S White Smooth For simplicity within this guide the color and texture designation are omitted and the term “TSW-730-MSMK” is used, unless otherwise noted. Installation Guide – DOC. 7415A Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK • 1... -
Page 4: Supplied Hardware
Multi-Surface Mount Kit for TSW-730 Crestron TSW-730-MSMK Supplied Hardware The TSW-730-MSMK consists of a plastic surface mount enclosure, metal mounting plate with adhesive backing, angled mounting bracket, plastic covers to protect cabling openings, raceway and appropriate screws and nuts for mounting. - Page 5 Crestron TSW-730-MSMK Multi-Surface Mount Kit for TSW-730 The dimensions of the TSW-730-MSMK are shown below and on the next page. Glass Mounting Plate Overall Dimensions 6.50 in (166 mm) 4.25 in (108 mm) Angle Mounting Bracket Overall Dimensions 6.25 in (159 mm) 0.23 in...
- Page 6 (77 mm) 3.25 in (83 mm) 4.74 in (121 mm) Plastic Enclosure Overall Dimensions (Bottom View) 8.76 in (223 mm) 0.93 in 0.63 in (24 mm) (16 mm) 4 • Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK Installation Guide – DOC. 7415A...
-
Page 7: Installation
Using a flathead screwdriver, carefully separate the back cover of the touch screen from the front of the unit. This part is not used. Refer to the following illustration. Installation Guide – DOC. 7415A Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK • 5... - Page 8 Plastic Enclosure Mounting Using Glass Mounting Plate Glass Glass Mounting Plate (4516855) Plastic Cover (2024491 or 2024492) Plastic Enclosure (2033441 or 2033442) Nut (4) #04-40 Hex (2004878) 6 • Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK Installation Guide – DOC. 7415A...
- Page 9 11. Secure the touch screen to the plastic enclosure with Phillips head screws. Alternatively, security Torx screws can be installed using a Torx screwdriver bit (both included with touch screen), as shown in the following illustration. Installation Guide – DOC. 7415A Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK • 7...
- Page 10 Secure Touch Screen with Screws (Mounting Surface Not Shown) 12. For a neat appearance, apply the peel-and-stick label that came with the TSW-730-MSMK (4517696 or 4517697) to the opposite side of the glass. Refer to the following illustration. 8 • Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK...
- Page 11 Attach Angle Mounting Bracket Glass Mounting Plate (4516855) Glass Angle Mounting Bracket (2033272 or 2033273) Nut (4) #04-40 Hex (2004878) Installation Guide – DOC. 7415A Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK • 9...
- Page 12 While snapping the unit into place, pull the network wiring to remove slack. Refer to the following illustration. 10 • Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK Installation Guide – DOC. 7415A...
- Page 13 Crestron TSW-730-MSMK Multi-Surface Mount Kit for TSW-730 Touch Screen Mounting Using TSW-730-MSMK and Angle Mounting Bracket (Exploded View) Glass Mounting Plate (4516855) Glass Angle Mounting Bracket (2033272 or 2033273) Touch Screen (Sold Separately) Screw (4) #04-40 x 1/4” Plastic Enclosure...
- Page 14 Drywall, Paneling, Concrete or Brick Mounting This section provides the steps required for assembly and installation of the TSW-730-MSMK onto drywall, paneling, concrete or brick. The touch screen can be flat mounted or angle mounted onto the surface by following the appropriate procedure below.
- Page 15 Secure the touch screen to the plastic enclosure with Phillip head screws. Alternatively, security Torx screws can be installed using a Torx screwdriver bit (both included with touch screen), as shown in illustration on page 8. Installation Guide – DOC. 7415A Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK • 13...
- Page 16 Refer to the following illustration. Attach Plastic Enclosure to Angle Mounting Bracket Mounting Surface Angle Mounting Bracket (2033272 or 2033273) Screw (4) #04-40 x 1/4” Plastic Enclosure (2007161) (2033441 or 2033442) 14 • Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK Installation Guide – DOC. 7415A...
- Page 17 While snapping the unit into place, pull the network wiring to remove slack. Refer to the following illustration. Touch Screen Mounting Using TSW-730-MSMK and Angle Mounting Bracket (Exploded View) Mounting Surface Angle Mounting Bracket...
-
Page 18: Resources
Crestron worldwide offices on the Crestron Web site (www.crestron.com/offices) for assistance within a particular geographic region. To post a question about Crestron products, log onto the Online Help section of the Crestron Web site (www.crestron.com/onlinehelp). First-time users must establish a user account to fully benefit from all available features. -
Page 19: Return And Warranty Policies
(property or economic damages inclusive) arising from the sale or use of this equipment. Crestron is not liable for any claim made by a third party or made by the purchaser for a third party. - Page 20 Crestron Electronics, Inc. Installation Guide – DOC. 7415A (2034624) 15 Volvo Drive Rockleigh, NJ 07647 Tel: 888.CRESTRON 06.13 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
