  • Page 1 UPER ® A+ SERVER 1012C-MRF USER'S MANUAL Revision 1.0c...
  • Page 2 This product, including software and documentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.

  • Page 3: About This Manual

    A+ Server 1012C-MRF. Installation and maintenance should be performed by experienced technicians only. The SuperServer A+ Server 1012C-MRF is a 1U rackmount server based on the SC512F-350B server chassis and the Supermicro H8SCM-F serverboard.
  • Page 4 A+ SERVER 1012C-MRF USER'S MANUAL Chapter 6: Advanced Chassis Setup Refer to Chapter 6 for detailed information on the SC512F-350B 1U rackmount server chassis. You should follow the procedures given in this chapter when installing, removing or reconfiguring SATA or peripheral drives and when replacing system power supply units and cooling fans.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    A+ SERVER 1012C-MRF USER'S MANUAL Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 Serial ATA ......................1-2 PCI Expansion Slots ..................1-2 Ethernet Ports ....................1-2 Onboard Controllers/Ports ................1-2 Graphics Controller ..................
  • Page 7 Table of Contents Checking the Serverboard Setup ..............2-9 Checking the Drive Bay Setup ...............2-11 Chapter 3 System Interface Overview ......................3-1 Control Panel Buttons ..................3-1 Reset ....................... 3-1 Power ......................3-1 Control Panel LEDs ..................3-2 NIC2 ........................ 3-2 NIC1 ........................
  • Page 8 A+ SERVER 1012C-MRF USER'S MANUAL Adding PCI Cards ................... 5-8 Serverboard Details ..................5-9 H8SCM-F Quick Reference ................5-10 Connector Definitions ..................5-12 Jumper Settings .................... 5-19 Explanation of Jumpers ................5-19 Onboard Indicators ..................5-22 5-10 IDE and SATA Drive Connections ..............5-23 5-11 Enabling SATA RAID ..................
  • Page 9 Table of Contents Appendix A BIOS Error Beep Codes Appendix BSystem Specifications...
  • Page 10 A+ SERVER 1012C-MRF USER'S MANUAL Notes...

  • Page 11: Chapter 1 Introduction

    Introduction Overview The A+ Server 1012C-MRF is a 1U server comprised of the SC512F-350B chassis and one H8SCM-F serverboards. Please refer to our web site for information on operating systems that have been certified for use with the server (www.supermicro.

  • Page 12: Serverboard Features

    Refer to the support area of our web site for procedures on setting up RAID on your system. PCI Expansion Slots Each A+ Server 1012C-MRF has available one PCI-E 2.0 x8 (in a x16) slot. Ethernet Ports An Intel® network controller is integrated into each of the serverboards to support two Gigabit LAN ports (100/1000Base-T/1000BaseTX, RJ45 output).

  • Page 13: Graphics Controller

    Chapter 1: Introduction Graphics Controller The H8SCM-F features an integrated Matrox G200eW graphics chip, which includes 16 MB of DDR2 memory. Other Features Other onboard features that promote system health include voltage monitors, auto- switching voltage regulators, chassis and CPU overheat sensors, Watch Dog/NMI, Wake-On-LAN (WOL), virus protection and BIOS rescue.

  • Page 14: Server Chassis Features

    A+ SERVER 1012C-MRF USER'S MANUAL Server Chassis Features The A+ Server 1012C-MRF is built on the SC512F-350B 1U rackmount server chassis. The following is a general outline of the main features of the SC512F-350B chassis. System Power When configured as the A+ Server 1012C-MRF, the SC512F-350B chassis features a single 320 Watts power supply.

  • Page 15: Contacting Supermicro

    Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...
  • Page 16 A+ SERVER 1012C-MRF USER'S MANUAL Notes...

  • Page 17: Chapter 2 Server Installation

    Read the Rack and Server Precautions in the next section. The A+ Server 1012C-MRF does not ship with a rack rail hardware package as the system can be rack mounted without the use of rails. An optional rack rail package is available if you wish to order from Supermicro.

  • Page 18: Choosing A Setup Location

    A+ SERVER 1012C-MRF USER'S MANUAL Choosing a Setup Location • Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches) and approximately 30 inches of clearance in the back of the rack to allow for sufficient airflow and ease in servicing.This product is for installation only in a Restricted Access Location (dedicated equipment rooms, service closets and the like).

  • Page 19: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Warning! To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to ensure that the system remains stable. The following guidelines are provided to ensure your safety: •...

  • Page 20: Installing The System Into A Rack

    A+ SERVER 1012C-MRF USER'S MANUAL Installing the System into a Rack This section provides information on installing the A+ Server 1012C-MRF into a rack unit. If the system has already been mounted into a rack, you can skip ahead to Sections 2-6 and 2-7.

  • Page 21: Installing With Rackmount Kit

    Chapter 2: Server Installation Installing with Rackmount Kit This is a guideline for installing the unit into a rack with the optional rack kit (MCP- 290-00004-03). You should also refer to the installation instructions that came with the rack unit you are using. Be aware that there are a variety of rack units on the market, which may mean the assembly procedure will differ slightly.
  • Page 22 Installing the Server into a Telco Rack If you are installing the A+ Server 1012C-MRF into a Telco type rack, follow the directions given on the previous pages for rack installation. The only difference in the installation procedure will be the positioning of the rack brackets to the rack.
  • Page 23 Chapter 2: Server Installation Figure 2-3. Installing the Server into a Rack (w/ Optional Rackmount Kit) Note: The figure above is for illustrative purposes only. Always install servers to the bottom of the rack first.
  • Page 24 A+ SERVER 1012C-MRF USER'S MANUAL Figure 2-4. Installing the Server into a Telco Rack...

  • Page 25: Checking The Serverboard Setup

    See Chapter 5 for instructions on processor installation. 2. The A+ Server 1012C-MRF server may have come with system memory already installed. Make sure all DIMMs are fully seated in their slots. For details on adding system memory, refer to Chapter 5.
  • Page 26 A+ SERVER 1012C-MRF USER'S MANUAL Figure 2-5. Accessing the Inside of the Server Remove these screws Remove these screws Remove this screw 2-10...

  • Page 27: Checking The Drive Bay Setup

    Chapter 2: Server Installation Checking the Drive Bay Setup Checking the Drives 1. For servicing the SATA and optional DVD-ROM drives, remove the top chassis cover. The SATA disk drive is located at the front of the chassis interior. 2. Refer to Chapter 6 if you need to reinstall a optional DVD-ROM drive to the system.
  • Page 28 A+ SERVER 1012C-MRF USER'S MANUAL Notes 2-12...

  • Page 29: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel as well as others on the drive carriers to keep you constantly informed of the overall status of the system as well as the activity and health of specific components.

  • Page 30: Control Panel Leds

    A+ SERVER 1012C-MRF USER'S MANUAL Control Panel LEDs The control panel located on the front of the SC512F-350B chassis has five LEDs. These LEDs provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective action you may need to take.

  • Page 31: Power

    Chapter 3: System Interface Power Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating.
  • Page 32 A+ SERVER 1012C-MRF USER'S MANUAL Notes...

  • Page 33: Chapter 4Standardized Warning Statements For Ac Systems

    Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our web site at http://www.supermicro.com/ about/policies/safety_information.cfm. Warning Definition Warning! This warning symbol means danger.
  • Page 34 A+ SERVER 1012C-MRF USER'S MANUAL Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 35 Warning Statements for AC Systems ‫جسذٌة‬ ‫اصابة‬ ً‫تتسبب ف‬ ‫حالة ٌوكي أى‬ ً‫اًك ف‬ ‫خطز‬ ًٌ‫ٌع‬ ‫هذا الزهز‬ !‫تحذٌز‬ ‫الذوائز‬ ‫بالوخاطز الٌاجوة عي‬ ‫ي على علن‬ ، ‫ك‬ ‫هعذات‬ ‫تعول على أي‬ ‫قبل أى‬ ‫الكهزبائٍة‬ ‫حىادث‬ ‫أي‬ ‫وقىع‬ ‫وٌع‬ ‫ل‬ ‫الىقائٍة‬...

  • Page 36: Installation Instructions

    A+ SERVER 1012C-MRF USER'S MANUAL Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de...

  • Page 37: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、...

  • Page 38: Power Disconnection Warning

    A+ SERVER 1012C-MRF USER'S MANUAL ‫في‬ ‫التي تم تثبيتها‬ ‫مه الدوائرالقصيرة‬ ‫الحمايت‬ ‫معداث‬ ‫يعتمد على‬ ‫هذا المنتج‬ ‫المبنى‬ ‫أكثر من‬ ‫ليس‬ ‫وقائي‬ ‫ال‬ ‫الجهاز‬ ‫تقييم‬ ‫أن‬ ‫تأكد من‬ 20A, 250V 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에...
  • Page 39 Chapter 4: Warning Statements for AC Systems Warnung Das System muss von allen Quellen der Energie und vom Netzanschlusskabel getrennt sein, das von den Spg.Versorgungsteilmodulen entfernt wird, bevor es auf den Chassisinnenraum zurückgreift, um Systemsbestandteile anzubringen oder zu entfernen. ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema.

  • Page 40: Equipment Installation

    A+ SERVER 1012C-MRF USER'S MANUAL Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden.

  • Page 41: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalificeerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 42: Battery Handling

    A+ SERVER 1012C-MRF USER'S MANUAL ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .)'‫כלי אבטחה בלבד (מפתח, מנעול וכד‬ ‫محظورة‬ ‫مناطق‬ ٍ‫نتركُبها ف‬ ‫هذه انىحذة‬ ‫تخصيص‬ ‫تم‬ ،‫أداة خاصت‬ ‫من خالل استخذاو‬...
  • Page 43 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 44: Redundant Power Supplies

    A+ SERVER 1012C-MRF USER'S MANUAL Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 45: Backplane Voltage

    Chapter 4: Warning Statements for AC Systems ‫امداد الطاقة‬ ‫بوحدات‬ ‫عدة اتصاالت‬ ‫جهاز‬ ‫ال‬ ‫يكون لهذا‬ ‫قد‬ ‫الكهرباء‬ ‫عن‬ ‫وحدة‬ ‫ال‬ ‫لعسل‬ ‫كافة االتصاالت‬ ‫يجب إزالة‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 46: Comply With Local And National Electrical Codes

    A+ SERVER 1012C-MRF USER'S MANUAL Attention Lorsque le système est en fonctionnement, des tensions électriques circulent sur le fond de panier. Prendre des précautions lors de la maintenance. ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬...

  • Page 47: Product Disposal

    Chapter 4: Warning Statements for AC Systems ¡Advertencia! La instalacion del equipo debe cumplir con las normas de electricidad locales y nacionales.Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬...

  • Page 48: Hot Swap Fan Warning

    A+ SERVER 1012C-MRF USER'S MANUAL Warnung Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen. ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement.
  • Page 49 Chapter 4: Warning Statements for AC Systems 当您从机架移除风扇装置，风扇可能仍在转动。小心不要将手指、螺丝起子和其他 物品太靠近风扇 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 50: Power Cable And Ac Adapter

    Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certified cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only. 電源コードとACアダプター 製品を設置する場合、 提供または指定された接続ケーブル、 電源コードとACアダプター...
  • Page 51 Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifiés qui ont UL ou CSA indiqué sur le code pour tous les autres appareils électriques que les produits désignés par Supermicro seulement.
  • Page 52 Elektrisch apparaat en veiligheidsinformatiebladen wet verbiedt het gebruik van UL of CSA gecertificeerde kabels die UL of CSA die op de code voor andere elektrische apparaten dan de producten die door Supermicro alleen. 4-20...

  • Page 53: Chapter 5 Advanced Serverboard Setup

    Chapter 4: System Safety Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to install the H8SCM-F serverboard into the SC512F-350B chassis, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are also described. A layout and quick reference chart are included in this chapter for your reference.

  • Page 54: I/O Port And Control Panel Connections

    A+ SERVER 1012C-MRF USER'S MANUAL I/O Port and Control Panel Connections The I/O ports are color coded to make setting up your system easier. See Figure 5-1 below for the colors and locations of the various I/O ports. Figure 5-1. I/O Port Locations and Definitions Rear I/O Ports 1.

  • Page 55: Processor And Heatsink Installation

    CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. • Refer to the Supermicro web site for updates on CPU support. Installing the Processors 1. Begin by removing the cover plate that protects the CPU.
  • Page 56 A+ SERVER 1012C-MRF USER'S MANUAL 3. Align pin 1 of the CPU with pin 1 of the socket. Once aligned, carefully place the CPU into the socket. Do not drop the CPU on the socket, move the CPU horizontally or vertically or rub the CPU...

  • Page 57: Installing A Passive Heatsink

    Chapter 4: System Safety Installing a Passive Heatsink To install the SNK-0022+ Passive Heatsink, use the following procedure: Installing a SNK-0022+ Passive Heatsink Note: Do not apply any thermal grease to the heatsink - the required amount has already been applied. 1.

  • Page 58: Installing Memory

    Populating two adjacent slots at a time with memory modules of the same size and type will result in interleaved (128-bit) memory, which is faster than non-interleaved (64-bit) memory. Note: Check the Supermicro web site for recommended DIMMs. Installing Memory 1. Insert each memory module vertically into its slot, paying attention to the notch along the bottom of the module to prevent inserting the module incorrectly (see Figure 2-1).

  • Page 59: Dimm Module Population Configuration

    Chapter 4: System Safety Figure 5-4. DIMM Installation Notch Notch To Install: Insert module vertically and press down until it snaps into place. Pay attention to Front View the alignment notch at the bottom. To Remove: Use your Note: Notch should align with the receptive thumbs to gently push key point on the slot.

  • Page 60: Adding Pci Cards

    The reduction in memory availability is disproportional. Adding PCI Cards PCI Express Slot The 1012C-MRF server includes a preinstalled riser card designed specifically for use in the SC512F-350B 1U rackmount chassis. This riser card supports one full height PCI Express card to fit inside the chassis.

  • Page 61: Serverboard Details

    Chapter 4: System Safety Serverboard Details Figure 5-5. H8SCM-F Serverboard Layout COM1 JPG1 JPL2 JPL1 SR5650 SATA0 SATA1 SP5100 JBT1 SATA2 SATA3 BATTERY SATA4 SATA5 JWD1 USB2/3 IDE#1 FAN4 FAN3 USB6 Notes: Jumpers not indicated are for test purposes only. Not all ports, jumpers or LED Indicators are available on all serverboards.

  • Page 62: H8Scm-F Quick Reference

    A+ SERVER 1012C-MRF USER'S MANUAL H8SCM-F Quick Reference Jumper Description Default Setting JBT1 CMOS Clear (See Section 5-8) JCF1 Compact Flash Master/Slave Closed (Master) JI2C1/JI2C2 I2C to PCI-E Slot Enable/Disable Both Open (Disabled) JPB1 BMC Enable/Disable Pins 1-2 (Enabled) JPG1...
  • Page 63 Chapter 4: System Safety Connector Description COM1/COM2 COM1 Serial Port/Header FAN 1-5 Chassis/CPU Fan Headers IDE#1 IDE Disk Drive Connector IPMI LAN (H8SCM-F only) Dedicated IPMI LAN Port (H8SCM-F only) Speaker Header Front Panel Connector Chassis Intrusion Header JOH1 Overheat Warning Header JIPMB (H8SCM-F only) System Management Bus Header for the IPMI Slot JPI2C1...

  • Page 64: Connector Definitions

    A+ SERVER 1012C-MRF USER'S MANUAL Connector Definitions ATX Power 24-pin Connector Pin Definitions Power Connectors Pin# Definition Pin # Definition A 2 4 - p i n m a i n p o w e r s u p p l y +3.3V...
  • Page 65 Chapter 4: System Safety Power Fail LED PWR Fail LED Pin Definitions The Power Fail LED connection is (JF1) located on pins 5 and 6 of JF1. Refer to Pin# Definition the table on the right for pin definitions. 3.3V Power Fail LED Overheat/Fan Fail LED (OH) OH/Fan Fail LED...
  • Page 66 A+ SERVER 1012C-MRF USER'S MANUAL Power On LED Power LED Pin Definitions The Power On LED connector is (JF1) located on pins 15 and 16 of JF1. This Pin# Definition connection is used to provide LED indication of power being supplied to Power LED the system.

  • Page 67: Chassis Intrusion

    Chapter 4: System Safety Chassis Intrusion Chassis Intrusion Pin Definitions A Chassis Intrusion header is located (JL1) at JL1. Attach the appropriate cable to Pin# Definition inform you of a chassis intrusion. Battery voltage Intrusion signal USB Headers Universal Serial Bus Headers Pin Definitions (USB2/3, Four USB 2.0 headers (USB2/3 USB4/5)
  • Page 68 A+ SERVER 1012C-MRF USER'S MANUAL SGPIO SGPIO Header Pin Definitions (T-SGPIO1/TSGPIO2) The T-SGPIO1/ T-SGPIO2 (Serial Pin# Definition Pin # Definition G e n e r a l P u r p o s e I n p u t / O u t p u t )
  • Page 69 Chapter 4: System Safety ATX PS/2 Keyboard and PS/2 PS/2 Keyboard/Mouse Pin Mouse Ports Definitions PS2 Keyboard PS2 Mouse The ATX PS/2 keyboard and PS/2 mouse are located next to the Pin# Definition Pin# Definition Back Panel USB Ports 0/1 on the KB Data Mouse Data motherboard.
  • Page 70 A+ SERVER 1012C-MRF USER'S MANUAL Overheat LED Overheat LED Pin Definitions C o n n e c t a n L E D t o t h e J O H 1 (JOH1) header to provide warning of chassis Pin# Definition overheating.

  • Page 71: Jumper Settings

    Chapter 4: System Safety Jumper Settings Connector Pins Explanation of Jumpers To modify the operation of the Jumper motherboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two Setting pins to change the function of the connector.
  • Page 72 A+ SERVER 1012C-MRF USER'S MANUAL LAN1/2 Enable/Disable LAN1/2 En/Disable Jumper Settings (JPL1/JPL2) Change the setting of jumper JPL1 or Jumper Setting Definition JPL2 to enable or disable the LAN1 or LAN2 Ethernet port. See the table Pins 1-2 Enabled on the right for jumper settings. The...
  • Page 73 Chapter 4: System Safety Onboard Speaker Enable/Disable Onboard Speaker Enable/Disable Pin Definitions (JD1) The JD1 header allows you to use Pins Definition either an external speaker or the internal (onboard) speaker. To use 6 and 7 Jump for onboard speaker the internal onboard speaker, close 4 and 7 Attach external speaker wires...

  • Page 74: Onboard Indicators

    A+ SERVER 1012C-MRF USER'S MANUAL Onboard Indicators GLAN LED Link Speed Activity GLAN LEDs There are two LAN ports (LAN1/2) on the motherboard. Each Ethernet LAN GLAN Activity Indicator port has two LEDs. The Yellow LED (Right) LED Settings on the right indicates connection and...

  • Page 75: 5-10 Ide And Sata Drive Connections

    Chapter 4: System Safety Power LED Power LED (DP2) DP2 is an Onboard Power LED. State System Status When this LED is lit, it means power is present on the serverboard. Be Standby power present on motherboard sure to turn off the system and unplug No power connected the power cord(s) before removing or installing components.

  • Page 76: Ide Connector

    A+ SERVER 1012C-MRF USER'S MANUAL IDE Connector IDE Drive Connector Pin Definitions (IDE#1) There is one IDE connector on the Pin# Definition Pin # Definition serverboard. See the table on the right Reset IDE Ground for pin definitions. Host Data 7...

  • Page 77: 5-11 Enabling Sata Raid

    OS installation. Building a Driver Diskette You must first build a driver diskette from Supermicro drivers for your system. Drivers can be found at ftp://ftp.supermicro.com. (You will have to create this disk on a computer that is already running and with the OS installed.) Building a Driver Diskette 1.

  • Page 78: Enabling Sata Raid In The Bios

    A+ SERVER 1012C-MRF USER'S MANUAL Enabling SATA RAID in the BIOS Before installing the Windows Operating System, you must change some settings in BIOS. Boot up the system and hit the <Del> key to enter the BIOS Setup Utlility. After the Setup Utility loads, 1.

  • Page 79: Using The Adaptec Raid Utility

    Chapter 4: System Safety Figure 5-5.Adaptec RAID Utility Program Screen Using the Adaptec RAID Utility The Adaptec RAID Utility program is where you can define the drives you want to include in the RAID array and the mode and type of RAID. Installing the RAID Driver During OS Installation You may also use the procedure below to install the RAID driver during the Window's OS installation:...

  • Page 80: 5-12 Installing Software

    A+ SERVER 1012C-MRF USER'S MANUAL 5-12 Installing Software The Supermicro ftp site contains drivers and utilities for your system at ftp://ftp. supermicro.com. Some of these must be installed, such as the chipset driver. After accessing the ftp site, go into the CDR_Images directory and locate the ISO file for your motherboard.

  • Page 81: Superdoctor Iii

    Chapter 4: System Safety SuperDoctor III The SuperDoctor III program is a Web base management tool that supports remote ® management capability. It includes Remote and Local Management tools. The local management is called SD III Client. The SuperDoctor III program allows you to monitor the environment and operations of your system.
  • Page 82 A+ SERVER 1012C-MRF USER'S MANUAL Figure 5-8. Supero Doctor III Interface Display Screen (Remote Control) Note: The SuperDoctor III program and User’s Manual can be downloaded from the Supermicro web site at http://www.supermicro.com/products/accessories/software/ SuperDoctorIII.cfm.For Linux, we recommend that you use the SuperoDoctor II application instead.

  • Page 83: 5-13 Serverboard Battery

    Chapter 4: System Safety 5-13 Serverboard Battery Caution: There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarites (see Figure 2-9). This battery must be replaced only with the same or an equivalent type recommended by the manufacturer (CR2032).
  • Page 84 A+ SERVER 1012C-MRF USER'S MANUAL Notes 5-32...

  • Page 85: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform maintenance on the SC512F-350B chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the next step.

  • Page 86: Control Panel

    Details on JF1 can be found in Chapter 5. System Fans The 1012C-MRF server employs two sets of 4-cm counter-rotating fans to provide cooling. Each fan unit is made up of two fans joined back-to-back, which rotate in opposite directions.

  • Page 87: System Fan Failure

    Chapter 6: Advanced Chassis Setup System Fan Failure If a fan fails, the remaining fans will ramp up to full speed and the overheat/fan fail LED on the control panel will blink on and off. Replace any failed fan at your earliest convenience with the same type and model (the system can continue to run with a failed fan).

  • Page 88: Drive Bay Installation/Removal

    Note: Only the optional a "slim" DVD-ROM will fit in the 1012C-MRF. Serial ATA Drive Installation The SATA drive is not hot-swappable, meaning system power must be turned off before installing or removing.

  • Page 89: Optional Dvd-Rom Drive Installation/Removal

    The top cover of the chassis must be opened to gain full access to the DVD- ROM drive bay. The optional DVD-ROM must have a "slim" profile to fit into the 1012C-MRF. If you cannot remove the top cover with the system remaining in the rack, follow the procedure below.
  • Page 90 A+ SERVER 1012C-MRF USER'S MANUAL Figure 6-3. Removing the DVD-ROM Drive...

  • Page 91: Power Supply

    Chapter 6: Advanced Chassis Setup Power Supply The 1012C-MRF server has a single 320 Watts power supply. This power supply has the capability of operating at a 100 or 240 input voltage. You must power down the system and then unplug the AC power cord to completely remove power from the system before removing the power supply.
  • Page 92 A+ SERVER 1012C-MRF USER'S MANUAL Notes...

  • Page 93: Chapter 7 Bios

    Chapter 7: BIOS Chapter 7 BIOS Introduction This chapter describes the AMIBIOS™ Setup utility for the H8SCM-F serverboard. The 16 Mb AMI BIOS® is stored in a flash chip and can be easily upgraded using a floppy disk-based program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 94: Main Menu

    A+ SERVER 1012C-MRF USER'S MANUAL Main Menu When you first enter AMI BIOS Setup Utility, you will see the Main Menu screen. You can always return to the Main Menu by selecting the Main tab on the top of the screen with the arrow keys.

  • Page 95: Processor And Clock Options

    Chapter 7: BIOS Wait for F1 if Error This setting controls the system response when an error is detected during the boot sequence. When enabled, BIOS will stop the boot sequence when an error is detected, at which point you will need to press the F1 button to re-enter the BIOS setup menu.
  • Page 96 A+ SERVER 1012C-MRF USER'S MANUAL GART Error Reporting This option should remain disabled for normal operation. The driver developer may enable this option for testing purposes. Options are Enabled or Disabled. Microcode Update This setting Enables or Disables microcode updating.

  • Page 97: Advanced Chipset Control

    Chapter 7: BIOS  Advanced Chipset Control  NorthBridge Configuration  Memory Configuration Bank Interleaving Select Auto to automatically enable a bank-interleaving memory scheme when this function is supported by the processor. The options are Auto and Disabled. Node Interleaving This option enables node memory interleaving.

  • Page 98: Ide Configuration

    A+ SERVER 1012C-MRF USER'S MANUAL  DRAM Timing Configuration DRAM Timing Config This option allows you to set the DRAM timing configuration for the system. Options include Auto or Manual. Memory Clock Speed This options sets the memory clock speed. Options include 200 Mhz, 266 Mhz, 333 Mhz, 400 Mhz, 533 Mhz, 667 Mhz, 800 Mhz and 933 Mhz.
  • Page 99 Chapter 7: BIOS OnChip SATA Type Use this setting to set the OnChip SATA type. Options include Native IDE, RAID, AHCI and Legacy IDE. RAID Codebase This submenu appears when you choose "RAID" from the "OnChip SATA Type" setting above. This setting allows you to select the codebase for your RAID setup.
  • Page 100 A+ SERVER 1012C-MRF USER'S MANUAL which has a data transfer rate of 8.3 MBs. Select 3 to allow BIOS to use PIO mode 3, which has a data transfer rate of 11.1 MBs. Select 4 to allow BIOS to use PIO mode 4, which has a data transfer rate of 16.6 MBs. This setting generally works with all hard disk drives manufactured after 1999.

  • Page 101: Superio Device Configuration

    Chapter 7: BIOS PCI IDE Busmaster Use this setting to Enable or Disable BIOS enabled uses of PCI Busmastering for reading or writing to IDE drives. ROM Scan Ordering This setting determines which kind of option ROM activates prior to another. Options include Onboard First and Addon First.

  • Page 102: Remote Access Configuration

    A+ SERVER 1012C-MRF USER'S MANUAL becomes unavailable. Select "2F8/IRQ3" to allow the serial port to use 2F8 as its I/O port address and IRQ 3 for the interrupt address. Options include Disabled, 2F8/IRQ3, 3E8/IRQ4 and 2F8/IRQ3. Serial Port 2 Attribute This option allows you to set COM2 as a normal serial port or as virtual COM for SOL.

  • Page 103: Hardware Health Configuration

    Chapter 7: BIOS Sredir Memory Display Delay Use this setting to set the delay in seconds to display memory information. Options are No Delay, 1 sec, 2 secs and 4 secs.  Hardware Health Configuration CPU Overheat Alarm This setting allows you to specify the type of alarm for CPU overheating. Options include The Early Alarm and The Default Alarm.

  • Page 104: Acpi Configuration

    A+ SERVER 1012C-MRF USER'S MANUAL Early Alarm is enabled when the Tctl value = 65, and is disabled when the Tctl value drops from 65 to 62. Default Alarm (default setting) is enabled when the Tctl value = 70, and is disabled when the Tctl value drops from 70 to 67.

  • Page 105: Trusted Computing

    Chapter 7: BIOS Headless Mode Use this setting to Enable or Disable headless operation mode through ACPI. ACPI Version Features Use this setting the determine which ACPI version to use. Options are ACPI v1.0, ACPI v2.0 and ACPI v3.0.  Trusted Computing TCG/TPM Support This setting enables/disables TPM/TCG (TPM 1.1/1.2) support in BIOS.

  • Page 106: Event Log Configuration

    A+ SERVER 1012C-MRF USER'S MANUAL Configuration Protocol) server in the network it is attached to, and request the next available IP address. The options are DHCP and Static. The following items are assigned IP addresses automatically if DHCP is selected under IP Address Source above: IP Address This submenu sets the IP address source as either Static or DHCP.

  • Page 107: Security Menu

    Chapter 7: BIOS Clear Event Log Selecting this and pressing the Enter key clears the system event log. SR56x0 (RD890S) PCIE Error Log This setting allows you set an error log ofr PCIE errors. Options include Yes or No. Security Menu AMI BIOS provides a Supervisor and a User password.

  • Page 108: Boot Menu

    A+ SERVER 1012C-MRF USER'S MANUAL Boot Menu The Boot Menu is accessible only when the "Load Onboard LAN Option ROM" setting (in the PCI/PnP Configuration menu) is enabled.  Boot Device Priority This feature allows you to prioritize the boot sequence from the list of available devices.

  • Page 109: Exit Menu

    Chapter 7: BIOS Exit Menu Select the Exit tab from AMI BIOS Setup Utility screen to enter the Exit BIOS Setup screen. Save Changes and Exit When you have completed the system configuration changes, select this option to leave BIOS Setup and reboot the computer, so the new system configuration parameters can take effect.
  • Page 110 A+ SERVER 1012C-MRF USER'S MANUAL Notes 7-18...

  • Page 111: Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 112 A+ SERVER 1012C-MRF/GIBXF/GIQXF USER'S MANUAL Notes...

  • Page 113: System Specifications

    Appendix C: System Specifications Appendix B System Specifications Processors Dual AMD Opteron 4000 series (AMD Socket C32 type) processors Note: please refer to our website for details on supported processors. Chipset One AMD SR5650 chipset and one SP5100 Southbridge chipset BIOS 16 Mb AMI BIOS®...

  • Page 114: System Cooling

    A+ SERVER 1012C-MRF USER'S MANUAL Weight Gross (Bare Bone): 17 lbs. (7.71 kg.) System Cooling Two 4-cm counter-rotating cooling fans (fan speed controlled by BIOS setting) System Input Requirements AC Input Voltage: 180-240 VAC Rated Input Current: 7.2A (180V) to 9.5 (240V)
  • Page 115 Appendix C: System Specifications Notes...
  • Page 116 A+ SERVER 1012C-MRF USER'S MANUAL (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.

Table of Contents
