A+ SERVER 1012C-MRF USER'S MANUAL
3-3

Control Panel LEDs

The control panel located on the front of the SC512F-350B chassis has five LEDs.
These LEDs provide you with critical information related to different parts of the
system. This section explains what each LED indicates when illuminated and any
corrective action you may need to take.
Information LED: See the following table for the status shown by this LED.
Status
Continously on and red
Blinking red (1 Hz)
Blinking red (0.25 Hz)
Solid blue
Blinking blue

NIC2

Indicates network activity on LAN2 when flashing .

NIC1

Indicates network activity on LAN1 when flashing .

HDD

This light indicates SATA and/or DVD-ROM drive activity when flashing.
Information LED
Description
An overheat ocondition has occured. (This may be caused by cable congestion.)
Fan failure: check for an inoperative fan.
Power failure: check for an inoperative power supply.
Local UID has been activated. Use this function to locate the server in a rack
environment.
Remote UID has been activated. Use this function to locate the server from a
remote location.
3-2
