A+ SERVER 1012C-MRF USER'S MANUAL
SGPIO
The T-SGPIO1/ T-SGPIO2 (Serial
G e n e r a l P u r p o s e I n p u t / O u t p u t )
headers provide a bus between the
SATA controller and the backpane to
provide SATA enclosure management
functions. Connect the appropriate
cable from the backplane to the
T-SGPIO1 header to utilize SATA
management functions on your system.
Trusted Platform Module Header
The JLPC1 header is used to connect
a Trusted Platform Module (TPM),
available separately from a third-party
vendor. A TPM is a security device that
allows encryption and authentication of
hard drives, disallowing access if the
TPM associated with it is not installed
in the system. See the table on the
right for pin definitions.
Power SMB (I
2
The Power System Management Bus
( C) connector (JPI
I2
the power suppply, fan and system
temperatures. See the table on the
right for pin definitions.
C) Connector
C1) monitors
2
SGPIO Header Pin Definitions
(T-SGPIO1/TSGPIO2)
Pin# Definition
1 NC
3 Ground
5 Load
7 NC
Note: NC indicates no connection.
Trusted Platform Module Header
Pin Definitions (JLPC1 )
Pin# Definition
1 LCLK
3 LFRAME
5 LRESET
7 LAD3
9 VCC3
11 LAD0
13 RSV0
15 SB3V
17 GND
19 LPCPD
Power SMB
Pin Definitions
Pin# Definition
1
2
3
4
5
5-16
Pin # Definition
2 NC
4 Data
6 Ground
8 NC
Pin# Definition
2 GND
4 No Pin
6 VCC5
8 LAD2
10 LAD1
12 GND
14 RSV1
16 SERIRQ
18 CLKRUN
20 RSV2
(JPI2C1)
Clock
Data
PWR Fail
Ground
+3.3V
