A+ SERVER 1012C-MRF USER'S MANUAL
Jumper Description
JBT1 CMOS Clear
JCF1 Compact Flash Master/Slave
JI2C1/JI2C2 I2C to PCI-E Slot Enable/Disable
JPB1 BMC Enable/Disable
JPG1 VGA Enable/Disable
JPL1 LAN 1 Enable/Disable
JPL2 LAN 2 Enable/Disable
JWD1 Watch Dog
LED
LAN Ports
Dedicated IPMI LAN (H8SCM-F only)
DP1
DP2

H8SCM-F Quick Reference

Description
LEDs for the LAN Ethernet ports
LEDs for the dedicated IPMI LAN Ethernet port (H8SCM-F only)
LED for BMC Heartbeat
LED for Serverboard Power-On
5-10
Default Setting
(See Section 5-8)
Closed (Master)
Both Open (Disabled)
Pins 1-2 (Enabled)
Pins 1-2 (Enabled)
Pins 1-2 (Enabled)
Pins 1-2 (Enabled)
Pins 1-2 (Reset)
