Cisco TelePresence System Codec C90 and Profile 65" Dual using C90
Contents
Technical specifications for Profile 65" Dual
UNIT DELIVERED COMPLETE WITH:
Full HD LCD Display, Codec C90, PrecisionHD Camera
(1080p), Touch 8 user interface device, remote control,
microphones, Digital Audio Module, integrated speakers
and cabling
MONITOR
• Two 65" Full HD LCD, 16:9, 1080 × 1920 resolution
BASE
• Floor standing footplate
• Wall mount on pedestal
BANDWIDTH
The same as Codec C90
FIREWALL TRAVERSAL
The same as Codec C90
VIDEO STANDARDS
The same as Codec C90
VIDEO FEATURES
The same as Codec C90
VIDEO INPUTS (13 INPUTS)
The same as Codec C90
VIDEO OUTPUTS (5 OUTPUTS)
The same as Codec C90
LIVE VIDEO RESOLUTIONS (ENCODE/DECODE)
The same as Codec C90
AUDIO STANDARDS
The same as Codec C90
AUDIO FEATURES
The same as Codec C90
All specifications are subject to change without notice, system specifics may vary.
All images in these materials are for representational purposes only, actual products may differ.
Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other countries. A listing of Cisco's trademarks can be
found at www.cisco.com/go/trademarks. Third party trademarks mentioned are the property of their respective owners. The use of the word partner does not
imply a partnership relationship between Cisco and any other company.
June 2013
D14635.13 Profile C90 and Codec C90 Administrator Guide TC7.0, DECEMBER 2013.
Introduction
Web interface
AUDIO INPUTS (14 INPUTS)
The same as Codec C90
AUDIO OUTPUTS (8 OUTPUTS)
The same as Codec C90
DUAL STREAM
The same as Codec C90
MULTIPOINT SUPPORT
The same as Codec C90
MULTISITE FEATURES
The same as Codec C90
PROTOCOLS
The same as Codec C90
EMBEDDED ENCRYPTION
The same as Codec C90
IP NETWORK FEATURES
The same as Codec C90
IPV6 NETWORK SUPPORT
The same as Codec C90
CISCO UNIFIED COMMUNICATIONS MANAgER
The same as Codec C90
SECURITY FEATURES
The same as Codec C90
NETWORK INTERFACES
The same as Codec C90
OTHER INTERFACES
The same as Codec C90
PRECISIONHD 1080P CAMERA
The same as Codec C90
System settings
SYSTEM MANAgEMENT
The same as Codec C90, as well as
• Cisco TelePresence Touch 8 user interface device
DIRECTORY SERVICES
The same as Codec C90
POWER
• Auto-sensing power supply
• 100-120/200-240 VAC, 60/50 Hz
• Maximum power rating complete system, 1400 W
• Normal operation power consumption, 1100 W
• Standby power consumption, 160 W
OPERATINg TEMPERATURE AND HUMIDITY
• 0° C to 35° C (32° F to 95° F) ambient temperature
• 10% to 90% relative humidity (RH)
STORAgE AND TRANSPORT TEMPERATURE
• -20° C to 60° C (-4° F to 140° F) at RH 10–90%
(non-condensing)
DIMENSIONS
• Height: 65 in. / 165 cm
• Width: 120 in. / 300 cm
• Depth: 5.9 in. / 15 cm
• Weight: 660 lbs / 300 kg
MTBF PRODUCT RELIABILITY/MTBF
The predicted reliability is expressed in the expected
random Mean Time Between Failures (MTBF) for the
electronic components for Codec C90 and PrecisionHD
1080p camera based on the Power On Hours:
Power On Hours (POH) > 69 000 hours
Useful Life Cycle > 6 years
ISO 9001 certificate is available upon request
139
www.cisco.com — Copyright © 2010-2013 Cisco Systems, Inc. All rights reserved.
Administrator Guide
Setting passwords
Appendices
Appendices
APPROVALS
EU/EEC
• Directive 2006/95/EC (Low Voltage Directive)
- Standard EN 60950-1
• Directive 2004/108/EC (EMC Directive)
- Standard EN 55022, Class A
- Standard EN 55024
- Standard EN 61000-3-2/-3-3
• Directive 2011/65/EU (RoHS)
Warning: This is a class A product. In a domestic
environment this product may cause radio interference
in which case the user may be required to take
adequate measures.
USA
• Approved according to UL 60950-1
• Complies with FCC15B Class A
Note: This equipment has been tested and found to
comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference when the equipment is operated in
a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. Operation of this equipment in a
residential area is likely to cause harmful interference
in which case the user will be required to correct the
interference at his own expense.
Canada
• Approved according to CAN/CSA C22.2 No. 60950-1
• This Class A digital apparatus complies with Canadian
ICES-003
• Cet appareil numérique de la classe A est conforme à
la norme NMB-003 du Canada
