Video Input Source [1..5] Visibility
Define the visibility of the video input source in the menus on the user interface.
Requires user role: ADMIN
Value space: <Never/Always/IfSignal>
Never: Set to Never when the input source is not expected to be used as a presentation
source.
Always: When set to Always, the menu selection for the video input source will always be
visible on the graphical user interface.
IfSignal: When set to IfSignal, the menu selection for the video input source will only be
visible when a presentation source is connected to the video input.
Video Input Source 1 Visibility: IfSignal
Example:
Video Input Source [1..5] CameraControl Mode
Select whether or not to enable camera control for the selected video input source when the
video input is active.
Requires user role: ADMIN
Value space: <Off/On>
Off: Disable camera control.
On: Enable camera control.
Video Input Source 1 CameraControl Mode: On
Example:
Video Input Source [1..5] CameraControl CameraId
Select the ID of the camera in the Visca chain that is connected to this camera source. The
CameraId setting represents the camera's position in the Visca chain.
Requires user role: ADMIN
Value space: <1/2/3/4/5/6/7>
Range: Select the ID of the camera in the Visca chain.
Video Input Source 1 CameraControl CameraId: 1
Example:
D14635.13 Profile C90 and Codec C90 Administrator Guide TC7.0, DECEMBER 2013.
Introduction Web interface System settings System settings
Video Input Source [1..5] OptimalDefinition Profile
The Video Input Source Quality setting must be set to Motion for the optimal definition settings
to take any effect.
The optimal definition profile should reflect the lighting conditions in your room and the quality
of the video input (camera); the better the lighting conditions and video input, the higher the
profile. Then, in good lighting conditions, the video encoder will provide better quality (higher
resolution or frame rate) for a given call rate.
Generally, we recommend using the Normal or Medium profiles. However, when the lighting
conditions are good, the High profile can be set in order to increase the resolution for a given
call rate.
Some typical resolutions used for different optimal definition profiles, call rates and transmit
frame rates are shown in the table below. It is assumed that dual video is not used. The
resolution must be supported by both the calling and called systems.
Use the Video Input Source OptimalDefinition Threshold60fps setting to decide when to use the
60 fps frame rate.
Typical resolutions used for different optimal definition profiles, call rates and frame rates
Optimal
Frame
Definition
rate
Profile
256 kbps 768 kbps
Normal 512 × 288 1024 × 576
Medium 640 × 360 1280 × 720
30 fps
High 768 × 448 1280 × 720
Normal 256 × 144 512 × 288
60 fps Medium 256 × 144 768 × 448
High 512 × 288 1024 × 576
.
* The resolution will be 1280 × 720 for older codecs without 1080p60 support.
Requires user role: ADMIN
Value space: <Normal/Medium/High>
Normal: Use this profile for a normally to poorly lit environment. Resolutions will be set rather
conservative.
Medium: Requires good and stable lighting conditions and a good quality video input. For
some call rates this leads to higher resolution.
High: Requires nearly optimal video conferencing lighting conditions and a good quality video
input in order to achieve a good overall experience. Rather high resolutions will be used.
Video Input Source 1 OptimalDefinition Profile: Normal
Example:
107 www.cisco.com — Copyright © 2010-2013 Cisco Systems, Inc. All rights reserved.
Administrator Guide
Setting passwords Appendices
Call rate
1152 kbps 1472 kbps 2560 kbps 4 Mbps
1280 × 720 1280 × 720 1920 × 1080 1920 × 1080 1920 × 1080
1280 × 720 1280 × 720 1920 × 1080 1920 × 1080 1920 × 1080
1280 × 720 1920 × 1080 1920 × 1080 1920 × 1080 1920 × 1080
768 × 448 1024 × 576 1280 × 720 1280 × 720 1920 × 1080
1024 × 576 1024 × 576 1280 × 720 1920 × 1080
1280 × 720 1280 × 720 1920 × 1080 1920 × 1080
*
6 Mbps
*
1920 × 1080
* *
1920 × 1080
* *
