Da-Lite TENSIONED EXECUTIVE ELECTROL Specification

S
UGGESTED SPECIFICATIONS: _________________________ projection screen(s), __________________(H) x ________________ (W),
operated 120 volt (60 Hz) not more than 2.2 amp. Three wire quick reversal motor especially designed for the purpose, to be ball
bearing and oiled for life. With automatic thermal overload cut-out and integral interlocking gears. To have pre-set but adjustable limit
switches to automatically stop screen surface in the "down" position. Stop action to be positive to prevent coasting. The roller to be
of rigid metal at least 3" in diameter and mounted on two heavy duty brackets equipped with self-aligning bearings. Screen surface to
be seamless, flame retardant and mildew resistant vinyl with black masking borders standard. Each side of the fabric to have tab guide
cable system to maintain even lateral tension and hold surface flat. Custom slat bar with added weight maintains vertical tension on
the screen surface. The ends of the slat to be protected by heavy duty plastic caps enclosing a preset adjustable mechanism for
screen tensioning. Case to be of wood, with double top for extra rigidity and strength. Motor compartment to be metal lined. A
section of the bottom of the case shall be equipped with hinges and connected to the drive mechanism so that it opens and closes
automatically with the lowering and raising of the screen surface. The door will lift to the closed position where a micro switch shall
cut off the electrical current to the motor. Balance of the bottom panel shall be pegged to manual opening to provide access. Hinges
shall be mounted to allow matching of the bottom panel to the ceiling. (Specify Type 1 and 2 or Type 3 hinge, as required.) Case to
be finished with a black primer coat, ready to accept final finish by others. To be complete with three position control switch with
cover plate. Screen to be listed by Underwriters' Laboratories and CSA.
All viewing surfaces will be seamless.
All viewing surfaces are standard with black backing except Da-Tex
Audio Vision, High Contrast Audio Vision and High Contrast Cinema Perf available in sizes up to 87" x 116" in Video Format and 78" x 139"
in HDTV Format.
Viewing
Area
H x W Cm
43" x 57" 109 x 145
50" x 67" 127 x 170
60" x 80" 152 x 203
69" x 92" 175 x 234
87" x 116" 221 x 295
108" x 144" 274 x 366
120" x 160" 305 x 406
Viewing
Area
H x W Cm
45" x 80" 114 x 203
52" x 92" 132 x 234
54" x 96" 137 x 244
58" x 104" 147 x 264
65" x 116" 165 x 295
78" x 139" 198 x 353
Viewing Area
H x W
50" x 50" 127 x 127
60" x 60" 152 x 152
70" x 70" 178 x 178
84" x 84" 213 x 213
6' x 8' 183 x 244
8' x 8' 244 x 244
7' x 9' 213 x 274
9' x 9' 274 x 274
8' x 10' 244 x 305
10' x 10' 305 x 305
9' x 12' 274 x 366
12' x 12' 366 x 366
*Add 7" to overall length for mounting brackets.
All screens standard with 12" black drop at the top.
Extra drop may alter case dimensions. Contact Da-Lite for details.
Overall case length dimensions ±
TENSIONED EXECUTIVE
ELECTROL
Automatic Electric Projection Screen Model
SPECIFICATION DATA
VIDEO (NTSC 4:3) FORMAT DIMENSIONS
Nominal
Diagonal
In.
72"
84"
100"
120"
150"
180"
200"
HDTV (16:9) FORMAT DIMENSIONS
Nominal
Diagonal
In.
92"
106"
110"
119"
133"
159"
SQUARE FORMAT DIMENSIONS
*Overall Length of Case
Cm In.
86 3 / "
4
97 / "
3
4
109 1 / "
4
125 3 / "
4
135 3 / "
4
139 1 / "
4
149 3 / "
4
148 1 / "
4
163 1 / "
4
160 1 / "
4
183 3 / "
4
193 1 / "
4
1 / ".
4
®
and Dual Vision.
®
*Overall Length of Case
Cm In.
183 92 3 / "
4
213 103 3 / "
4
254 117 / "
3
4
305 131 3 / "
4
381 158 3 / "
4
457 183 3 / "
4
508 200 3 / "
4
*Overall Length of Case
Cm In.
234 116 1 / "
4
269 128 3 / "
4
279 133 1 / "
4
302 141 3 / "
4
338 154 3 / "
4
404 179 3 / "
4
Cm
220
248
277
319
345
354
380
377
415
407
467
491
Specifications subject to change without notice.
Detailed dimensional drawings, wiring diagrams and installation
instructions available upon request.
Custom formats and sizes available upon request.
DA-LITE SCREEN COMPANY, INC.
3100 North Detroit Street
Post Office Box 137
Warsaw, Indiana 46581-0137
Phone: 574-267-8101
800-622-3737
Fax: 574-267-7804
Toll Free Fax: 877-325-4832
www.da-lite.com
e-mail: info@da-lite.com
Approx. Ship.
Wt.
Cm Lbs.
236 156
264 183
299 211
335 244
403 279
467 323
510 353
Approx. Ship.
Wt.
Cm Lbs.
295 211
327 244
338 250
360 261
393 279
457 300
Approx. Ship. Wt.
Lbs.
140
155
183
211
244
244
267
267
279
279
323
328
electrically
Kg
70.8
83.0
95.7
110.7
126.6
146.5
160.1
Kg
95.7
110.7
113.4
118.4
126.6
136.1
Kg
63.5
70.3
83.0
95.7
110.7
110.7
120.2
120.2
126.6
126.6
146.5
148.8
